ProjectIntroduction - What does the car do?
This project was developed to meet the requirements of the ELEC 424 final assignment, which involved designing and building an autonomous RC car capable of navigating a track using OpenCV for image processing. The system detects lane lines and stop signs, and includes a speed encoder to help maintain a consistent velocity. We integrated various hardware components—including a servo motor, DC motor, and Raspberry Pi—into the car's design. Drawing inspiration from existing project scripts (linked below), we developed a program that successfully navigated the track in the RYON building, as demonstrated in the video below.
This work draws from the following instructable:
User raja_961, “Autonomous Lane-Keeping Car Using Raspberry Pi and OpenCV”. Instructables. URL: https://www.instructables.com/Autonomous-Lane-Keeping-Car-Using-Raspberry-Pi-and/
And the following existing ELEC 424 project:
Users reddot313, Wonjune Kim, Youhan Wu, “graDudes -”. Hackster. URL: https://www.hackster.io/439751/gradudes-9d9a6eHow we determined the resolution, proportional gain, and derivative gain
Despite the camera being able to support resolutions higher than 720p, we selected a camera resolution of 320x340 to balance image clarity and processing speed, ensuring the Raspberry Pi 5 could process frames in real time while still detecting lanes reliably. To tune the PD controller for steering, we initially set a low proportional gain and observed the car's response to lane deviation. We incrementally increased the proportional gain (KP = 0.07) until the car began to over correct and oscillate, then introduced derivative gain (KD = 0.08) to dampen these oscillations and stabilize steering. This was accomplished through iterative testing and analyzing the generated plots allowing us to fine-tune these values.
Howwehandledthestoppaper
To detect the red stop paper, we converted each frame to the HSV color space and applied two binary masks to capture low and high ranges of red hue, one with values around 0-10, and the other with values around 160-180. We focused the stop detection on the bottom ~20% of the frame where the stop paper was expected to appear, reducing false positives from irrelevant regions and ensuring an optimal stopping location for the car. A stop was triggered when the combined red pixel area was greater than a predefined threshold, indicating a stop paper, and subsequently raising the stop flag to pass into update steering to execute the stop. After the first stop, we introduced a frame cooldown to prevent repeated triggering, and for the second stop, the first_stop_done flag ensured that the car would not resume after stopping.
PlotsFigure 1: plot showing error, steering duty cycle, and speed dutycycle versus frame number for an entire run of the track
Figure 2: plot showing error, proportional response (gain * error), derivativeresponse (derivative gain * derivative of the error), and (optionally) integral response (integral gain * integral of the error) versus frame number for an entire run of the track
PictureofVehiclewithHardwareonit
VideoDemo
Main Python Code
Python# Autonomous Lane-Keeping Car with Dual-Lane Detection and Video Output
# Adapted from prior ELEC 424 projects and external sources:
#
# User raja_961, Autonomous Lane-Keeping Car Using Raspberry Pi and OpenCV. Instructables.
# URL: https://www.instructables.com/Autonomous-Lane-Keeping-Car-Using-Raspberry-Pi-and/
#
# Also referenced ELEC 424 past projects posted on Hackster:
# URL: https://www.hackster.io/elec424/projects?sort=published
import RPi.GPIO as GPIO
import time
import cv2
import numpy as np
from datetime import datetime
import matplotlib.pyplot as plt
import subprocess
import re
# Video Playback
fourcc = cv2.VideoWriter_fourcc(*'XVID') #Writes the video
out_transformed = cv2.VideoWriter('processed_output.avi', fourcc, 15.0, (320, 240)) #Transforms output for our specs
# GPIO Setup
DRIVE_PIN = 18 #Main motor set to pin 18 for PWM
SERVO_PIN = 19 #Servo motor set to pin 19 for PWM
FREQ = 50 #Set PWM Frequency to be 50Hz
NEUTRAL_DUTY = 7.5 #Defualt to 7.5 duty cycle used for making car and servo motors neutral
CONSTANT_DRIVE_DUTY = 7.99 #For constant driving instead of Decoder for testing
TOLERANCE = 0.001 #Constant for upping/lowering the speed
ENCODER_READ_INTERVAL = 10
frame_num = 0
TARGET_SPEED = 7.99 # Target speed in pulses/s
GPIO.setmode(GPIO.BCM)
GPIO.setup(DRIVE_PIN, GPIO.OUT) #Initialize drive 18 pin to an output
GPIO.setup(SERVO_PIN, GPIO.OUT) #Initialize servo 19 pin to an output
drive = GPIO.PWM(DRIVE_PIN, FREQ) #Initialize PWM Output for pin 18
servo = GPIO.PWM(SERVO_PIN, FREQ) #Initialize PWM Output for pin 19
drive.start(NEUTRAL_DUTY) #Default the drive motor to neutral so it is idle
servo.start(NEUTRAL_DUTY) #Default the servo motor to neutral so the car is facing forward and not turned
#PD Controller Variables
KP = 0.07 #Proportional Gain Value
KD = 0.08 #Derivative Gain Value
last_error = 0 #Error flag
CAMERA_OFFSET = 0 #USED FOR TESTING, had camera offset in case because camera initially tilted
#Stop Detection Variables
first_stop_done = False #Stop sign initializtion flag
stopping = False #Final stop sign initialization flag
stop_check_interval = 3
stop_detection_cooldown = 0
COOLDOWN_FRAMES = 300 #How many frames the red color is masked for before Pi detects red again, so you can move past first stop sign
RESUME_DELAY = 5.0 # How long until you start moving again after stopping the first time
frame_counter = 0 #Frame flag to count how many frames it has been
#Data Logger for plots!!!
log_data = {
"frame": [],
"error": [],
"steering_duty": [],
"proportional": [],
"derivative": [],
"speed": []
}
#All Image processig for lane detection and red light detection
def process_image(frame):
global first_stop_done, stopping, frame_counter, stop_detection_cooldown #Initialize all the variables defined above in the function
frame = cv2.resize(frame, (320, 240)) #Set resolution for camera to be 320x240
lane_center = 160 #Half of 320 so center of frame is that
centers = [] #
#Stop Sign detection (HSV red in bottom region)
stop_detected = False #Initially stop not detected
if not stopping and stop_detection_cooldown == 0 and frame_counter % stop_check_interval == 0:
hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV) #convert image to HSV color space
#Intervals for red. Red wraps around HSV values so need two intervals
lower_red1 = np.array([0, 100, 100])
upper_red1 = np.array([10, 255, 255])
lower_red2 = np.array([160, 100, 100])
upper_red2 = np.array([180, 255, 255])
hsv_roi = hsv[190:240, :] #focus on bottom 50 pixels of the image for the stop sign
mask1 = cv2.inRange(hsv_roi, lower_red1, upper_red1) #red mask for first HSV interval
mask2 = cv2.inRange(hsv_roi, lower_red2, upper_red2) #red mask for second HSV interval
red_mask = cv2.bitwise_or(mask1, mask2) #Combine the two masks for a complete mask
cv2.imwrite("y-red_mask.jpg", red_mask) #Write an image every run to be used for debugging making sure we pick up contours
red_area = np.sum(red_mask) / 255 # counting number of red pixels in the image
stop_detected = red_area > 3000 #if teh number is greater than threshold you have found stop sign
#blue lane detection in HSV for lane detection
hsv = cv2.cvtColor(frame, cv2.COLOR_BGR2HSV) #convert image to HSV for blue
#Interval for blue mask so we can do lane detection in HSV
lower_blue = np.array([80, 30, 20])
upper_blue = np.array([140, 255, 255])
blue_mask = cv2.inRange(hsv, lower_blue, upper_blue) #Blue mask for lane detetcion
cv2.imwrite("y-blue_mask.jpg", blue_mask) # Write an image every run to be used for debugging making sure we pick up blue contours
roi = blue_mask[100:240, :] #focus on lower half of image where lanes are
contours, _ = cv2.findContours(roi, cv2.RETR_EXTERNAL, cv2.CHAIN_APPROX_SIMPLE) #find the contours in the image for the blue mask
contours = sorted(contours, key=cv2.contourArea, reverse=True)[:2] #Take the two biggest contours and store them
for c in contours:
M = cv2.moments(c) #Using the contours in the image calculate the center of the contours
if M['m00'] > 0:
cx = int(M['m10'] / M['m00']) #Calculating centroid of each contour
cy = int(M['m01'] / M['m00']) + 120 #Accounting for cropped detection of lower half
centers.append((cx, cy)) #append the contours
cv2.circle(frame, (cx, cy), 5, (0, 255, 0), -1) #Draw green dot in the centroid of the line
cv2.drawContours(frame, [c + [0, 120]], -1, (255, 0, 0), 2) # draw blue outline for the contour for detection
if len(centers) == 2: #If two lanes detected then computing lane center between the two
lane_center = int((centers[0][0] + centers[1][0]) / 2) #Take the two centroids and determine center
cv2.line(frame, (lane_center, 120), (lane_center, 240), (0, 0, 255), 2) #Draw red line to show projected center line for car
cv2.putText(frame, f'Lane Center: {lane_center}', (lane_center - 60, 115), #Put a text showing the pixel number that is center
cv2.FONT_HERSHEY_SIMPLEX, 0.5, (255, 255, 255), 1)
error = lane_center - (160 + CAMERA_OFFSET) #horizontal lane error between calculated center and actual center, camera offset in zero but was previously used for debugging camera tilt
out_transformed.write(frame) #use the frame for video playback
return error, stop_detected #return the error and if a stop is detected
def update_steering(error, frame_num):
global last_error #Using the error from process_image we can update for correction of steering
#PD Controller Logic
proportional = KP * error #proportional part of the PD controller, Proportional gain and error mutiplied
derivative = KD * (error - last_error) #Derivative part of PD controller, Derivative gain multiplied by the derivative error
control_signal = proportional + derivative #add the proportional and derivative parts together to get complete PD
duty_cycle = NEUTRAL_DUTY + control_signal #Update duty cycle based on a initial duty cycle of 7.5
duty_cycle = max(6.0, min(9.0, duty_cycle)) #The max the car can turn is 9 and 6 so cap the values at the interval
if duty_cycle == 6.0 or duty_cycle == 9.0: #If the number calculated for duty cycle exceeds interval print error for debugging
print(f"[SATURATED] Frame {frame_num}, Error: {error}")
servo.ChangeDutyCycle(duty_cycle) #Update the servo for correction with the new duty cycle
#Log all the data calculated for plots being the error,frame number, duty cycle, P and D values, and the speed of the car
log_data["frame"].append(frame_num)
log_data["error"].append(error)
log_data["steering_duty"].append(duty_cycle)
log_data["proportional"].append(proportional)
log_data["derivative"].append(derivative)
log_data["speed"].append(speed)
last_error = error #Update the error flag for next cycke
return duty_cycle
def drive_forward():
drive.ChangeDutyCycle(CONSTANT_DRIVE_DUTY) #Car updates PWM with the variable
def stop_drive():
drive.ChangeDutyCycle(NEUTRAL_DUTY) #Reset PWM to neutral
#Old function for saving data for logs CSV file, instead switching to outputting plots automatically
# def save_logs():
# timestamp = datetime.now().strftime("%Y%m%d_%H%M%S")
# with open(f"run_{timestamp}.csv", "w") as f:
# f.write("frame,error,steering_duty,proportional,derivative,speed\n")
# for i in range(len(log_data["frame"])):
# f.write(f"{log_data['frame'][i]},{log_data['error'][i]},{log_data['steering_duty'][i]},"
# f"{log_data['proportional'][i]},{log_data['derivative'][i]},{log_data['speed'][i]}\n")
def plot_logs():
# Plot 1: PD Values over Time
fig, ax1 = plt.subplots()
t_ax = np.array(log_data["frame"]) #Frames as x axis
#P and D values as compared to the frames
ax1.plot(t_ax, log_data["proportional"], '-', label="P values", color='blue')
ax1.plot(t_ax, log_data["derivative"], '-', label="D values", color='orange')
ax2 = ax1.twinx()
#Error values plotted as well
ax2.plot(t_ax, log_data["error"], '--r', label="Error")
#Labels for each of the data logged
ax1.set_xlabel("Frames")
ax1.set_ylabel("PD Value")
ax2.set_ylim(-90, 90)
ax2.set_ylabel("Error Value")
#Title the plot and add legend
plt.title("PD Values over time")
fig.legend(loc='upper right')
fig.tight_layout()
#Make an output png for the plot
plt.savefig("pd_plot.png")
plt.clf()
# Plot 2: Speed and Steer Duty Cycle, and Error vs. Time
fig, ax1 = plt.subplots()
t_ax = np.array(log_data["frame"]) #Frame as x axis
#Speed, steering duty cycle, and error plotted compared to the frames
ax1.plot(t_ax, log_data["speed"], '-', label="Speed", color='blue')
ax1.plot(t_ax, log_data["steering_duty"], '-', label="Steering", color='orange')
ax2 = ax1.twinx()
error = np.array(log_data["error"])
#Need to normalize the error
max_error = np.max(np.abs(error))
if max_error != 0:
normalized_error = error / max_error
else:
normalized_error = error
#Initialize the error on the plot with label "Error"
ax2.plot(t_ax, normalized_error, '--r', label="Error")
#Set labels and title and legend for the rest of the plot
ax1.set_xlabel("Frames")
ax1.set_ylabel("Speed and Steer Duty Cycle")
ax2.set_ylabel("Percent Error Value")
plt.title("Speed and Steer Duty Cycle, and error v.s. time")
fig.legend(loc='upper right') #Locate legend in top right part of frame
fig.tight_layout()
plt.savefig("voltage_plot.png") #Make a png file for this plot
plt.clf()
#Actual Script!!!!
# Read kernel log for speed
def read_kernel_log():
try:
result = subprocess.run(['dmesg'], capture_output=True, text=True)
return result.stdout
except Exception as e:
print(f"Error reading kernel log: {e}")
return ""
# Parse speed from kernel log
def parse_speed(log):
pattern = r"irq_handler - timing detected: \d+ ns, speed: (\d+\.\d+) pulses/s"
matches = re.findall(pattern, log)
if matches:
return float(matches[-1]) # Return the latest speed
return None
# Adjust speed to target 7.99
def adjust_speed(current_speed):
global CONSTANT_DRIVE_DUTY
if current_speed < TARGET_SPEED - TOLERANCE:
CONSTANT_DRIVE_DUTY += 0.001
print(f"[INFO] Increasing speed. Current: {current_speed:.2f}, New duty: {CONSTANT_DRIVE_DUTY:.3f}")
elif current_speed > TARGET_SPEED + TOLERANCE:
CONSTANT_DRIVE_DUTY -= 0.001
print(f"[INFO] Decreasing speed. Current: {current_speed:.2f}, New duty: {CONSTANT_DRIVE_DUTY:.3f}")
else:
print(f"[OK] Speed is within range: {current_speed:.2f}")
return CONSTANT_DRIVE_DUTY
try:
cap = cv2.VideoCapture(0) #Initialize the camera
cap.set(cv2.CAP_PROP_FRAME_WIDTH, 320) #Set the frame width to our resolution
cap.set(cv2.CAP_PROP_FRAME_HEIGHT, 240) #Set frame height to our resolution
time.sleep(2) #Have a 2 second delay
frame_num = 0
max_frames = 1000 #If the video was playing too long we used to have the while loop be going for the amount of frames of the max
while True:
ret, frame = cap.read() #frame from camera captures
if not ret:
continue #In event fram does not capture skip iteration
frame_counter += 1 #Still increment frame though!
if stop_detection_cooldown > 0: #When stop sign detected this if statement used to cooldown so the box does not get picked up again
stop_detection_cooldown -= 1 #Decrement to reset flag
print(f"Cooldown: {stop_detection_cooldown}") #Print statement for this
error, stop_detected = process_image(frame)
if frame_num % ENCODER_READ_INTERVAL == 0: # The line that the speed has been outputted on
log = read_kernel_log()
speed = parse_speed(log) # Valid speed
if speed is not None:
print(f"Speed from kernel: {speed:.2f} pulses/s")
adjust_speed(speed) # Something went wrong
else:
print("[WARN] No speed reading available")
speed = CONSTANT_DRIVE_DUTY
if stop_detected: #When the red stop sign is detected
print("Stop box detected!") #Print statement for it
stopping = True #Change the boolean
stop_drive() #Stop the car reset the PWM to neutral
time.sleep(RESUME_DELAY) #Have a delay until the car moves again for a full stop
if not first_stop_done: #After first stop say when the car resumes driving
print("Resuming after first stop")
first_stop_done = True #Set the flag so we know the first stop is concluded
stopping = False #no longer stopped drive
stop_detection_cooldown = COOLDOWN_FRAMES #Have a cooldown to make sure the red does not get detected again before it passes the sign
drive_forward() #Drive the car
else:
print("Final stop, exiting.") #If first stop done is true and you see red again after cooldown frames then stop for good!
break
else:
update_steering(error, frame_num) #Update PWM for servo based on lane detetcion
if not stopping:
drive_forward() #Keep car driving while updating
cv2.imshow('Live Feed', frame) #Show pocessed video in live feed
if cv2.waitKey(1) == ord('q'): #If q is pressed you can exit loop early, but did not really work we would just use CTRL^C instead
break
frame_num += 1 #Update the frame counter
finally:
# save_logs()
plot_logs() #Run the plot functions
cap.release() #Release the capture from camera
out_transformed.release() #release the transformed output of camera
cv2.destroyAllWindows() #Kill the CV
stop_drive() #Stop the car to neutral
drive.stop() #Stop the driving
servo.stop() #Stop the servo
GPIO.cleanup() #Clear all pins
Driver for the Optical Encoder
C/C++#include <linux/module.h>
#include <linux/init.h>
#include <linux/platform_device.h>
#include <linux/of_device.h>
#include <linux/mod_devicetable.h>
#include <linux/gpio/consumer.h>
#include <linux/interrupt.h>
#include <linux/ktime.h>
#include <linux/fs.h>
#include <linux/file.h>
#define DEBOUNCE_MS 5 // Debounce time in milliseconds
#define ENCODER_GPIO_NAME "encoder" // Matches "encoder-gpios" in DTS
#define PULSES_PER_REVOLUTION 360 // Example: 360 pulses per wheel revolution
#define WHEEL_CIRCUMFERENCE 0.2 // Example: 0.2 meters per revolution
#define ENCODER_DATA_FILE "/tmp/encoder_data" // File to write encoder data
#define SCALE_FACTOR 1000 // Scale factor for fixed-point arithmetic (e.g., 0.123 m/s -> 123)
static struct gpio_desc *encoder_gpio;
static unsigned int irq_number;
static ktime_t last_pulse_time;
static unsigned long pulse_count = 0;
static ktime_t last_rate_calc_time;
static unsigned long pulses_since_last_rate = 0;
// Function to calculate and log speed
static void log_encoder_speed(unsigned long pulses, s64 elapsed_us)
{
unsigned long pulse_rate_int, car_speed_int;
// Calculate pulse rate (pulses per second, scaled)
pulse_rate_int = (pulses * 1000000UL) / elapsed_us; // Integer pulses per second
pulse_rate_int *= SCALE_FACTOR; // Scale for precision
// Calculate speed (m/s, scaled)
car_speed_int = (pulse_rate_int / PULSES_PER_REVOLUTION) * (unsigned long)(WHEEL_CIRCUMFERENCE * SCALE_FACTOR);
// Log to kernel
pr_info("irq_handler - timing detected: speed: %d pulses/s\n", car_speed_int);
}
// Interrupt handler for encoder
// This function is called when the encoder is triggered
static irqreturn_t encoder_isr(int irq, void *dev_id)
{
ktime_t now = ktime_get();
s64 delta_us = ktime_us_delta(now, last_pulse_time);
// Debounce: ignore pulses closer than DEBOUNCE_MS
if (delta_us > (DEBOUNCE_MS * 1000)) {
pulse_count++;
pulses_since_last_rate++;
last_pulse_time = now;
// Check if 1 second has elapsed
s64 elapsed_us = ktime_us_delta(now, last_rate_calc_time);
if (elapsed_us >= 1000000) { // 1 second
// Call log_encoder_speed directly
log_encoder_speed(pulses_since_last_rate, elapsed_us);
pulses_since_last_rate = 0;
last_rate_calc_time = now;
}
}
return IRQ_HANDLED;
}
// Probe function
// This function is called when the driver is loaded
static int encoder_probe(struct platform_device *pdev)
{
int ret;
// Get encoder GPIO using libgpiod
encoder_gpio = devm_gpiod_get(&pdev->dev, ENCODER_GPIO_NAME, GPIOD_IN);
if (IS_ERR(encoder_gpio)) {
pr_err("Failed to get encoder GPIO: %ld\n", PTR_ERR(encoder_gpio));
return PTR_ERR(encoder_gpio);
}
// Set debounce (in microseconds)
ret = gpiod_set_debounce(encoder_gpio, DEBOUNCE_MS * 1000);
if (ret) {
pr_err("Failed to set debounce for encoder GPIO\n");
return ret;
}
// Get IRQ number
irq_number = gpiod_to_irq(encoder_gpio);
if (irq_number < 0) {
pr_err("Failed to get IRQ for encoder GPIO: %d\n", irq_number);
return irq_number;
}
// Request IRQ
ret = request_irq(irq_number, encoder_isr, IRQF_TRIGGER_RISING, "encoder_irq", NULL);
if (ret) {
pr_err("Failed to request IRQ %d: %d\n", irq_number, ret);
return ret;
}
// Initialize timing variables
last_pulse_time = ktime_get();
last_rate_calc_time = last_pulse_time;
pr_info("Encoder driver initialized\n");
return 0;
}
// Remove function
// This function is called when the driver is removed
static void encoder_remove(struct platform_device *pdev)
{
free_irq(irq_number, NULL);
pr_info("Encoder driver unloaded\n");
}
// Match table for encoder
// This table is used to match the driver with the correct device
static const struct of_device_id encoder_match_table[] = {
{ .compatible = "thechosen" },
{},
};
MODULE_DEVICE_TABLE(of, encoder_match_table);
// Platform driver for encoder
// It is for connecting the method implementations to the function pointers in the kernel
static struct platform_driver encoder_driver = {
.probe = encoder_probe,
.remove = encoder_remove,
.driver = {
.name = "encoder_driver",
.owner = THIS_MODULE,
.of_match_table = encoder_match_table,
},
};
module_platform_driver(encoder_driver);
MODULE_LICENSE("GPL");
MODULE_AUTHOR("ELEC 424 Team");
MODULE_DESCRIPTION("Optical encoder driver for speed control");
Device Tree File for the Encoder
Plain text/dts-v1/;
/plugin/;
/ {
fragment@0 {
target-path ="/";
__overlay__ {
encoder {
compatible = "thechosen";
encoder-gpios = <&gpio 17 0>;
};
};
};
};
Comments
