The Arduino Radar

This project basically functions by using an ultrasonic sensor, the Arduino and the Processing app.

IntermediateShowcase (no instructions)3,399
The Arduino Radar

Things used in this project

Hardware components

Ultrasonic Sensor - HC-SR04 (Generic)
Ultrasonic Sensor - HC-SR04 (Generic)
×1
Arduino UNO
Arduino UNO
×1

Software apps and online services

Arduino IDE
Arduino IDE
Processing

Story

Read more

Custom parts and enclosures

ultrasonic_sensor_yUKZ11v0h4.pde

Schematics

Please do not use the given diagram wirings. This is only as a demonstration.

Code

Processing Code

Python
import processing.serial.*;     // import serial library
Serial arduinoport;                  // declare a serial port
float x, y;                       // variable to store x and y co-ordinates for vertices
int radius = 350;               // set the radius of objects
int w = 300;                    // set an arbitary width value
int degree = 0;                 // servo position in degrees
int value = 0;                  // value from sensor
int motion = 0;                 // value to store which way the servo is panning
int[] newValue = new int[181];  // create an array to store each new sensor value for each servo position
int[] oldValue = new int[181];  // create an array to store the previous values.
PFont myFont;                   // setup fonts in Processing
int radarDist = 0;              // set value to configure Radar distance labels
int firstRun = 0;               // value to ignore triggering motion on the first 2 servo sweeps
/* create background and serial buffer */
void setup(){
// setup the background size, colour and font.
size(750, 450);
background (0); // 0 = black
myFont = createFont("verdana", 12);
textFont(myFont);
// setup the serial port and buffer
arduinoport = new Serial(this, Serial.list()[0], 9600);
}
/* draw the screen */
void draw(){
fill(0);                              // set the following shapes to be black
noStroke();                           // set the following shapes to have no outline
ellipse(radius, radius, 750, 750);    // draw a circle with a width/ height = 750 with its center position (x and y) set by the radius
rectMode(CENTER);                     // set the following rectangle to be drawn around its center
rect(350,402,800,100);                // draw rectangle (x, y, width, height)
if (degree >= 179) {                  // if at the far right then set motion = 1/ true we're about to go right to left
motion = 1;                         // this changes the animation to run right to left
}
if (degree <= 1) {                    // if servo at 0 degrees then we're about to go left to right
motion = 0;                         // this sets the animation to run left to right
}
/* setup the radar sweep */
/*
We use trigonmetry to create points around a circle.
So the radius plus the cosine of the servo position converted to radians
Since radians 0 start at 90 degrees we add 180 to make it start from the left
Adding +1 (i) each time through the loops to move 1 degree matching the one degree of servo movement
cos is for the x left to right value and sin calculates the y value
since its a circle we plot our lines and vertices around the start point for everything will always be the center.
*/
strokeWeight(7);                      // set the thickness of the lines
if (motion == 0) {                    // if going left to right
for (int i = 0; i <= 20; i++) {     // draw 20 lines with fading colour each 1 degree further round than the last
stroke(0, (10*i), 0);             // set the stroke colour (Red, Green, Blue) base it on the the value of i
line(radius, radius, radius + cos(radians(degree+(180+i)))*w, radius + sin(radians(degree+(180+i)))*w); // line(start x, start y, end x, end y)
}
} else {                              // if going right to left
for (int i = 20; i >= 0; i--) {     // draw 20 lines with fading colour
stroke(0,200-(10*i), 0);          // using standard RGB values, each between 0 and 255
line(radius, radius, radius + cos(radians(degree+(180+i)))*w, radius + sin(radians(degree+(180+i)))*w);
}
}
/* Setup the shapes made from the sensor values */
noStroke();                           // no outline
/* first sweep */
fill(0,50,0);                         // set the fill colour of the shape (Red, Green, Blue)
beginShape();                         // start drawing shape
for (int i = 0; i < 180; i++) {     // for each degree in the array
x = radius + cos(radians((180+i)))*((oldValue[i])); // create x coordinate
y = radius + sin(radians((180+i)))*((oldValue[i])); // create y coordinate
vertex(x, y);                     // plot vertices
}
endShape();                           // end shape
/* second sweep */
fill(0,110,0);
beginShape();
for (int i = 0; i < 180; i++) {
x = radius + cos(radians((180+i)))*(newValue[i]);
y = radius + sin(radians((180+i)))*(newValue[i]);
vertex(x, y);
}
endShape();
/* average */
fill(0,170,0);
beginShape();
for (int i = 0; i < 180; i++) {
x = radius + cos(radians((180+i)))*((newValue[i]+oldValue[i])/2); // create average
y = radius + sin(radians((180+i)))*((newValue[i]+oldValue[i])/2);
vertex(x, y);
}
endShape();
/* if after first 2 sweeps, highlight motion with red circle*/
if (firstRun >= 360) {
stroke(150,0,0);
strokeWeight(1);
noFill();
for (int i = 0; i < 180; i++) {
if (oldValue[i] - newValue[i] > 35 || newValue[i] - oldValue[i] > 35) {
x = radius + cos(radians((180+i)))*(newValue[i]);
y = radius + sin(radians((180+i)))*(newValue[i]);
ellipse(x, y, 10, 10);
}
}
}
/* set the radar distance rings and out put their values, 50, 100, 150 etc.. */
for (int i = 0; i <=6; i++){
noFill();
strokeWeight(1);
stroke(0, 255-(30*i), 0);
ellipse(radius, radius, (100*i), (100*i));
fill(0, 100, 0);
noStroke();
text(Integer.toString(radarDist+50), 380, (305-radarDist), 50, 50);
radarDist+=50;
}
radarDist = 0;
/* draw the grid lines on the radar every 30 degrees and write their values 180, 210, 240 etc.. */
for (int i = 0; i <= 6; i++) {
strokeWeight(1);
stroke(0, 55, 0);
line(radius, radius, radius + cos(radians(180+(30*i)))*w, radius + sin(radians(180+(30*i)))*w);
fill(0, 55, 0);
noStroke();
if (180+(30*i) >= 300) {
text(Integer.toString(180+(30*i)), (radius+10) + cos(radians(180+(30*i)))*(w+10), (radius+10) + sin(radians(180+(30*i)))*(w+10), 25,50);
} else {
text(Integer.toString(180+(30*i)), radius + cos(radians(180+(30*i)))*w, radius + sin(radians(180+(30*i)))*w, 60,40);
}
}
/* Write information text and values. */
noStroke();
fill(0);
rect(350,402,800,100);
fill(0, 100, 0);
text("Degrees: "+Integer.toString(degree), 100, 380, 100, 50);         // use Integet.toString to convert numeric to string as text() only outputs strings
text("Distance: "+Integer.toString(value), 100, 400, 100, 50);         // text(string, x, y, width, height)
text("Radar screen code ", 540, 380, 250, 50);
fill(0);
rect(70,60,150,100);
fill(0, 100, 0);
text("Screen Key:", 100, 50, 150, 50);
fill(0,50,0);
rect(30,53,10,10);
text("First sweep", 115, 70, 150, 50);
fill(0,110,0);
rect(30,73,10,10);
text("Second sweep", 115, 90, 150, 50);
fill(0,170,0);
rect(30,93,10,10);
text("Average", 115, 110, 150, 50);
noFill();
stroke(150,0,0);
strokeWeight(1);
ellipse(29, 113, 10, 10);
fill(150,0,0);
text("Motion", 115, 130, 150, 50);
}
/* get values from serial port */
void serialEvent (Serial arduinoport) {
String xString = arduinoport.readStringUntil('\n');  // read the serial port until a new line
if (xString != null) {  // if theres data in between the new lines
xString = trim(xString); // get rid of any whitespace just in case
String getX = xString.substring(1, xString.indexOf("V")); // get the value of the servo position
String getV = xString.substring(xString.indexOf("V")+1, xString.length()); // get the value of the sensor reading
degree = Integer.parseInt(getX); // set the values to variables
value = Integer.parseInt(getV);
oldValue[degree] = newValue[degree]; // store the values in the arrays.
newValue[degree] = value;
/* sets a counter to allow for the first 2 sweeps of the servo */
firstRun++;
if (firstRun > 360) {
firstRun = 360; // keep the value at 360
}
}
}

Arduino Code

C#
#include <Servo.h>
/*
  code for arduino bord ultrasonic radar system.
*/

Servo leftRightServo;         // set a variable to map the servo
int leftRightPos = 0;         // set a variable to store the servo position
const int numReadings = 10;   // set a variable for the number of readings to take
int index = 0;                // the index of the current reading
int total = 0;                // the total of all readings
int average = 0;              // the average
int echoPin = 6;              // the SRF05's echo pin
int initPin = 7;              // the SRF05's init pin
unsigned long pulseTime = 0;  // variable for reading the pulse
unsigned long distance = 0;   // variable for storing distance

/* setup the pins, servo and serial port */
void setup() {
  leftRightServo.attach(9);
  // make the init pin an output:
  pinMode(initPin, OUTPUT);
  // make the echo pin an input:
  pinMode(echoPin, INPUT);
  // initialize the serial port:
  Serial.begin(9600);
}

/* begin rotating the servo and getting sensor values */
void loop() {
  for (leftRightPos = 0; leftRightPos < 180; leftRightPos++) { // going left to right.
    leftRightServo.write(leftRightPos);
    for (index = 0; index <= numReadings; index++) {         // take x number of readings from the sensor and average them
      digitalWrite(initPin, LOW);
      delayMicroseconds(50);
      digitalWrite(initPin, HIGH);                           // send signal
      delayMicroseconds(50);                                 // wait 50 microseconds for it to return
      digitalWrite(initPin, LOW);                            // close signal
      pulseTime = pulseIn(echoPin, HIGH);                    // calculate time for signal to return
      distance = pulseTime / 58;                             // convert to centimetres
      total = total + distance;                              // update total
      delay(10);
    }
    average = total / numReadings;                             // create average reading

    if (index >= numReadings)  {                               // reset the counts when at the last item of the array
      index = 0;
      total = 0;
    }
    Serial.print("X");                                         // print leading X to mark the following value as degrees
    Serial.print(leftRightPos);                                // current servo position
    Serial.print("V");                                         // preceeding character to separate values
    Serial.println(average);                                   // average of sensor readings
  }
  /*
    start going right to left after we got to 180 degrees
    same code as above
  */
  for (leftRightPos = 180; leftRightPos > 0; leftRightPos--) { // going right to left
    leftRightServo.write(leftRightPos);
    for (index = 0; index <= numReadings; index++) {
      digitalWrite(initPin, LOW);
      delayMicroseconds(50);
      digitalWrite(initPin, HIGH);
      delayMicroseconds(50);
      digitalWrite(initPin, LOW);
      pulseTime = pulseIn(echoPin, HIGH);
      distance = pulseTime / 58;
      total = total + distance;
      delay(10);
    }
    average = total / numReadings;
    if (index >= numReadings)  {
      index = 0;
      total = 0;
    }
    Serial.print("X");
    Serial.print(leftRightPos);
    Serial.print("V");
    Serial.println(average);
  }
}
