WiFi Scan Using Zerynth (Python for Embedded and IoT)

In this tutorial, we'll see how to scan for WiFi networks, using Python on a microcontroller (WiPy 3.0 by Pycom, based on ESP32).

BeginnerFull instructions provided1 hour2,188
WiFi Scan Using Zerynth (Python for Embedded and IoT)

Things used in this project

Hardware components

Pycom WiPy 3.0
×1
Pycom Expansion Board 3.0
×1

Software apps and online services

Zerynth Studio
Zerynth Studio

Story

Read more

Schematics

Schamatics

Code

main.py

Python
################################################################################
# Zerynth wifi scan
#
# Created by Zerynth Team 2015 CC
# Authors: G. Baldi, D. Mazzei
################################################################################

# import streams & socket
import streams
import socket

# import the wifi interface
from wireless import wifi

# the wifi module needs a networking driver to be loaded
# in order to control the board hardware.
# FOR THIS EXAMPLE TO WORK, A NETWORK DRIVER MUST BE SELECTED BELOW

# uncomment the following line to use the CC3000 driver (Particle Core or CC3000 Wifi shields)
# from texas.cc3000 import cc3000 as wifi_driver

# uncomment the following line to use the BCM43362 driver (Particle Photon)
# from broadcom.bcm43362 import bcm43362 as wifi_driver

streams.serial()

# init the wifi driver!
# The driver automatically registers itself to the wifi interface
# with the correct configuration for the selected board
wifi_driver.auto_init()

# a list of security strings
wifi_sec=["Open","WEP","WPA","WPA2"]
try:
    print("Scanning for 15 seconds...")
    # start scanning for 15000 milliseconds
    res = wifi.scan(15000)

    # if everything goes well, res is a sequence of tuples
    # each tuple contains:
    # -ssid: the name of the network
    # -sec: the security type of the network, from 0 to 3
    # -rssi: the strength of the signal, from 0 to 127
    # -bssid: the mac address of the access point
    for ssid,sec,rssi,bssid in res:
        print(ssid,"::",wifi_sec[sec],":: strength ",rssi*100/127)
except Exception as e:
    print(e)
