Connected Safety Jacket

#include <SoftwareSerial.h>
#include "Arduino.h"
#include "KIM.h"
#include <avr/interrupt.h>
#include <avr/sleep.h>
#include <avr/wdt.h>
#include <SoftwareSerial.h>
#include <Wire.h>
#include "MMA7660.h"

#define RX_PIN 7
#define TX_PIN 8

SoftwareSerial kserial(RX_PIN, TX_PIN);
SoftwareSerial SoftSerial(2, 3);

KIM kim;

//GPS variables
String heure_tot, lat, NS, longi, EW, fix, nb_sat, precision, heure, minute;
int deg_lat, min_lat, deg_longi, min_longi;
unsigned int min_dec1,min_dec2,min_dec3;

void setup() {
  Serial.begin(4800);                       // Start PC serial port @ 4800 baud
  delay(100);
  Wire.begin();                             //Start the BPM sensor connection
  kim.set_SoftwareSerial(&kserial, 4800);   //Start UART connection with KIM @ 4800 baud
}

void loop() {
  //Variable initilization
  int aX_MAX=0, aY_MAX=0, aZ_MAX=0;
  int aX, aY, aZ;
  int BPM[60];
  int somme=0,den=0;
  int BPM_moy;
  int cpt=0;
  String GPS_GGA;
  int BAT, alert, wakup;
  Serial.println("Accelerometer measurements");
  for(cpt=0;cpt<810;cpt++)    //Cycle of 810*1s with only acceleration measurements
  {
    aX = measure_accX();      //X axis acceleration measurement
    aY = measure_accY();      //Y axis acceleration measurement
    aZ = measure_accZ();      //Z axis acceleration measurement
    //aX = simu_accX(0.95);   //X axis acceleration simulation fonction to emule the accelerometer
    //aY = simu_accY(0.63);   //Y axis acceleration simulation fonction to emule the accelerometer
    //aZ = simu_accZ(1.2);    //Z axis acceleration simulation fonction to emule the accelerometer
    aX_MAX=MAX(aX_MAX,aX);    //Store the max X axis acceleration value
    aY_MAX=MAX(aY_MAX,aY);    //Store the max Y axis acceleration value
    aZ_MAX=MAX(aZ_MAX,aZ);    //Store the max Z axis acceleration value
    delay(990);
  }
  Serial.println("Accelerometer + BPM measurements");
  for(cpt=810;cpt<870;cpt++)  //Cycle of 60*1s with only acceleration+BPM measurements
  {
    aX = measure_accX();
    aY = measure_accY();
    aZ = measure_accZ();
    //aX = simu_accX(0.95);
    //aY = simu_accY(0.63);
    //aZ = simu_accZ(1.2);
    aX_MAX=MAX(aX_MAX,aX);
    aY_MAX=MAX(aY_MAX,aY);
    aZ_MAX=MAX(aZ_MAX,aZ);
    BPM[cpt-810]=measure_BPM();   //BPM measurements
    //BPM[cpt-810]=simu_BPM(128); //BPM simulation fonction to emule the heart rate sensor
    delay(990);
  }
    //Start of the BPM average calculation
    for(int i=0;i<60;i++)
    {
      if(BPM[i]>0)
      {
      somme+=BPM[i];
      den++;
      }
    }
    BPM_moy=somme/den;
    //End of the BPM average calculation
    GPS_GGA = GPS_acquisition();      //GPS localisation
    //GPS_GGA = simu_GPS_GGA("154415.000,4839.4308,N,00214.6685,E,1,5,1.66,102.9,M,47.3,M,,*51");   //GPS trame simulation fonction to emule the GPS chip
    recept_val_GPS(GPS_GGA);          //GPS data treatment
    BAT = simu_BAT(87);               //Battery level simulation
    alert = simu_alert(1);            //Alert state simulation
    wakup = simu_Wakup(3);            //Wakupe victim indication simulation
    String TRANSMIT=conception_trame_sat(BAT,alert,wakup,BPM_moy,aX_MAX,aY_MAX,aZ_MAX);             //Initialization of the transmission string
    KIM_switch_on();                  //KIM1 switch on
    KIM_config("B1",300,1500);        //KIM1 config
    KIM_transmit(TRANSMIT);           //Satelite transmission (1st try)
    delay(1000);
    KIM_transmit(TRANSMIT);           //Satelite transmission (2nd try)
    delay(1000);
    KIM_transmit(TRANSMIT);           //Satelite transmission (3rd try)
    delay(1000);
    KIM_transmit(TRANSMIT);           //Satelite transmission (4th try)
    delay(1000);
    KIM_switch_off();                 //KIM1 switch off

}

void KIM_switch_on(){
    Serial.println(F("main-->Turning ON the Kim1"));
    kim.set_ModuleStateON();                  // Set the Kim1 On/Off pin HIGH and thus turn the Kim1 module ON
    kim.get_KIMPlatform_Info();
    delay(2000);
}

void KIM_config(String BAND, int FREQUENCY, int POWER){
    Serial.println(F("main-->Configuring the transmission parameters"));
    kim.set_TX_Band(BAND);                    // Assign the band for transmission using AT command
    kim.set_TX_OffsetFreq(FREQUENCY);         // Assign the transmission offset frequency for transmission using AT command
    kim.set_TX_Power(POWER);                  // Assign the power for transmission using AT command
    Serial.println(F("main-->Function called to check the values configured for the transmission parameters: "));
    kim.get_TransmissionParameters_Values();
}

void KIM_transmit(String HEXA_STRING){
    Serial.println(F("main-->-------- transmit hexadecimal user message -------"));
    Serial.print(F("main-->User message length:"));
    Serial.println(HEXA_STRING.length());
    Serial.print(F("main-->User Data:"));
    Serial.println(HEXA_STRING);
    String HEXA_MESSAGE = HEXA_STRING;
    String command = "AT+TX=" + HEXA_MESSAGE + "\r";
    Serial.print(F("Command :"));
    Serial.println(command);
    kim.send_ATCommand(command);
}

void KIM_switch_off() {
    Serial.println(F("main-->Stop the Kim1 and the Arduino board"));
    kim.set_ModuleStateOFF();
    kim.stop();
}

int measure_BPM()
{
    unsigned char c;
    Wire.requestFrom(0xA0 >> 1, 1);     // request 1 bytes from slave device
    while(Wire.available())
    {
        c = Wire.read();                // receive heart rate value (a byte)
    }
    return (int)(c);
}

int measure_accX()
{
  MMA7660 acc;
  acc.init();
  float ax, ay, az;
  acc.getAcceleration(&ax,&ay,&az);
  return (int)(ax*100);
}

int measure_accY()
{
  MMA7660 acc;
  acc.init();
  float ax, ay, az;
  acc.getAcceleration(&ax,&ay,&az);
  return (int)(ay*100);
}

int measure_accZ()
{
  MMA7660 acc;
  acc.init();
  float ax, ay, az;
  acc.getAcceleration(&ax,&ay,&az);
  return (int)(az*100);
}

int MAX(int a, int b)
{
  if(a<b)
  return b;
  else
  return a;
}

String GPS_acquisition()
{
  String trame_GPS_GGA, trame_GPS;
  SoftSerial.begin(9600);
  char buffer[64];                   // buffer array for data receive over serial port
  int count=0;
  int count_trame = 0;
  int etape = 0;
  if (SoftSerial.available())                     // if date is coming from software serial port ==> data is coming from SoftSerial shield
  {
    while(SoftSerial.available())               // reading data into char array
    {
      buffer[count++]=SoftSerial.read();      // writing data into array
      if(count == 64)break;
    }
     for (int i=0; i<count;i++)
     {
      Serial.print(buffer[i]);
      trame_GPS.concat(buffer[i]);
     }
     Serial.println();
     for(count_trame=0;((count_trame<count) or (etape == 6));count_trame++)
    {
      int buf_ascii = trame_GPS[count_trame];
      if(buf_ascii == 36)
      {
        etape = 1;
        count_trame++;
      }
      else
      { etape = 0; }
      buf_ascii = trame_GPS[count_trame];

      if((buf_ascii == 71)and(etape == 1))
      {
        etape = 2;
        count_trame++;
      }
      else
        {etape = 0; }
      buf_ascii = trame_GPS[count_trame];
      if((buf_ascii == 80)and(etape == 2))
      {
        etape = 3;
        count_trame++;
      }
      else
        {etape = 0; }
      buf_ascii = trame_GPS[count_trame];
      if((buf_ascii == 71)and(etape == 3))
      {
        etape = 4;
        count_trame++;
      }
      else
        {etape = 0;}
      buf_ascii = trame_GPS[count_trame];
      if((buf_ascii == 71)and(etape == 4))
      {
        etape = 5;
        count_trame++;
      }
      else
        {etape = 0;}
      buf_ascii = trame_GPS[count_trame];
      if((buf_ascii == 65)and(etape == 5))
      {
        etape = 6;
        count_trame++;
         int buf_ascii2 = buffer[count_trame];
         trame_GPS_GGA = "";
         for(int i = count_trame;(i<count);i++)
          {
            buf_ascii2 = trame_GPS[i];
            if(buf_ascii2== 36)
            {
              etape=0;
              trame_GPS_GGA = "";
    }
    else
      trame_GPS_GGA.concat(trame_GPS[i]);
  }
      }
      else
        {etape = 0;}
      buf_ascii = trame_GPS[count_trame];
     }

     for (int i=0; i<count;i++)
     {
        buffer[i]=NULL;
     }
     trame_GPS = "";
     count = 0;                                  // set counter of while loop to zero
  }
  delay(10);
  return trame_GPS_GGA;
}

 void recept_val_GPS(String trame_GPS_GGA)
/******************************************************
Splitting GPS data function

Global variables used:
String heure_tot, lat, NS, longi, EW, fix, nb_sat, precision, heure, minute;
int deg_lat, min_lat, deg_longi, min_longi;
******************************************************/
{
  //String s = "12345, 6789, 101112"; // exemple
  int n_av=0, n_ap =0;
  //double nb;
  //String subs, newStr="";
  int temp =0;
  String Stemp;


  n_av=0;
  n_ap = trame_GPS_GGA.indexOf(",",n_av+1);
  heure_tot = trame_GPS_GGA.substring(n_av+1, n_ap);
  heure = heure_tot.substring(0,1);
  minute = heure_tot.substring(2,3);
  n_av=n_ap;
  n_ap = trame_GPS_GGA.indexOf(",",n_av+1);
  lat = trame_GPS_GGA.substring(n_av+1, n_ap);
  n_av=n_ap;
  n_ap = trame_GPS_GGA.indexOf(",",n_av+1);
  NS = trame_GPS_GGA.substring(n_av+1, n_ap);
  n_av=n_ap;
  n_ap = trame_GPS_GGA.indexOf(",",n_av+1);
  longi = trame_GPS_GGA.substring(n_av+1, n_ap);
  n_av=n_ap;
  n_ap = trame_GPS_GGA.indexOf(",",n_av+1);
  EW = trame_GPS_GGA.substring(n_av+1, n_ap);
  n_av=n_ap;
  n_ap = trame_GPS_GGA.indexOf(",",n_av+1);
  fix = trame_GPS_GGA.substring(n_av+1, n_ap);
  n_av=n_ap;
  n_ap = trame_GPS_GGA.indexOf(",",n_av+1);
  nb_sat = trame_GPS_GGA.substring(n_av+1, n_ap);
  n_av=n_ap;
  n_ap = trame_GPS_GGA.indexOf(",",n_av+1);
  precision = trame_GPS_GGA.substring(n_av+1, n_ap);
  n_ap=0;
  n_ap = lat.indexOf(".",0);
  Stemp=lat.substring(0, n_ap);
  temp = Stemp.toInt();
  deg_lat = (int)(temp/100);
  temp = temp%100;
  Stemp="";
  Stemp=lat.substring(n_ap+1);
  min_lat = Stemp.toInt();
  min_lat = min_lat + temp*10000;
  n_ap=0;
  temp=0;
  Stemp="";
  n_ap = longi.indexOf(".",0);
  Stemp=longi.substring(0, n_ap);
  temp = Stemp.toInt();
  deg_longi = (int)(temp/100);
  temp = temp%100;
  Stemp="";
  Stemp=longi.substring(n_ap+1);
  min_longi = Stemp.toInt();
  min_longi = min_longi + temp*10000;
}

void conv_dec_bin_20b(long unsigned int dec)
/***********************************************************
Converts a <524,288 decimal value to a binary value of 20 bits
split into 3 bytes with min_dec1 per byte of byte weight
high and min_dec3 the low byte

Global variables used :
unsigned int min_dec1,min_dec2,min_dec3;
***********************************************************/
{
  long int dec_temp;
  double temp=0;

  min_dec1=0;
  min_dec2=0;
  min_dec3=0;
  for(int i=19;i>=16;i--)
  {
    dec_temp = dec-pow(2,i);
    if(dec_temp>=0)
    {
      dec=dec-pow(2,i);
      temp= temp + pow(2,i-16);
    }
  }
  min_dec1 = (unsigned int)(temp+1);
  temp = 0;
  for(int i=15;i>=8;i--)
  {
    dec_temp = dec-pow(2,i);
    if(dec_temp>=0)
    {
      dec=dec-pow(2,i);
      temp= temp+pow(2,i-8);
    }
  }
  min_dec2 = (unsigned int) (temp+1);
  temp = 0;
  for(int i=7;i>=0;i--)
  {
    dec_temp = dec-pow(2,i);
    if(dec_temp>=0)
    {
      dec=dec-pow(2,i);
      temp= temp+pow(2,i);
    }
  }
  min_dec3 = (unsigned int) (temp+1);
  temp = 0;
}

String conception_trame_sat(int niv_bat,int et_alerte,int Wakup,int BPM,int acc_x,int acc_y,int acc_z)

{
  String userdataS;
  String HEXA_STRING;
   unsigned int temp;
   userdataS=String(heure.toInt(),HEX);
   HEXA_STRING=generate_hexa_string(1,userdataS,HEXA_STRING);
   userdataS=String((minute.toInt() + Wakup*64),HEX);
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   if(NS=="N")
    userdataS=String(deg_lat,HEX);
   else
    userdataS=String((deg_lat+128),HEX);
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   userdataS=String(deg_longi,HEX);
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   if(NS=="N")
    userdataS=String(((int)(precision.toFloat()*10)),HEX);
   else
    userdataS=String((((int)(precision.toFloat()*10))+128),HEX);
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   conv_dec_bin_20b(((long unsigned int) min_lat));
   userdataS=String( min_dec3,HEX);
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   userdataS= String(min_dec2,HEX);
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   temp=min_dec1;
   conv_dec_bin_20b(((long unsigned int) min_lat));
   userdataS=String((temp+ (min_dec1*16)),HEX);
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   userdataS=String( min_dec2,HEX);
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   userdataS= String(min_dec3,HEX);
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   userdataS=String((niv_bat + 128*et_alerte),HEX);
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   userdataS=String(BPM,HEX);
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   if(acc_x<0)
   {
    if(acc_x>127)
      acc_x=127;
    userdataS=String((acc_x),HEX);
   }
   else
   {
    if(acc_x<-127)
     acc_x=-127;
    userdataS=String(((acc_x)+128),HEX);  //ajout du bit de signe
   }
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   if(acc_y<0)
   {
    if(acc_y>127)
      acc_y=127;
    userdataS=String((acc_y),HEX);
   }
   else
   {
    if(acc_y<-127)
     acc_y=-127;
    userdataS=String(((acc_y)+128),HEX);
   }
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   if(acc_z<0)
   {
    if(acc_z>127)
      acc_z=127;
    userdataS=String((acc_z),HEX);
   }
   else
   {
    if(acc_z<-127)
     acc_z=-127;
    userdataS=String(((acc_z)+128),HEX);
   }
   HEXA_STRING=generate_hexa_string(0,userdataS,HEXA_STRING);
   return HEXA_STRING;
}

String generate_hexa_string(int init,String USDT,String HS)
{
  String HEXA_STRING=HS;
  if (init==1)
    HEXA_STRING="";
    if(USDT.length()==1)
      HEXA_STRING+="0"+USDT;
    else
      HEXA_STRING+=USDT;
    Serial.println(HEXA_STRING);
  HEXA_STRING.toUpperCase();
  return HEXA_STRING;
}

 String simu_GPS_GGA(String GGA)
 {
  return GGA;
 }

int simu_BAT(int lv)
{
  return lv;
}

int simu_alert(int alt)
{
  return alt;
}

int simu_Wakup (int wkp)
{
  return wkp;
}

 int simu_BPM(int BPM)
 {
  return BPM;
 }

 int simu_accX(float X)
 {
  return int(X*100);
 }

 int simu_accY(float Y)
 {
  return int(Y*100);
 }

  int simu_accZ(float Z)
 {
  return int(Z*100);
 }
