LEDsaber : Color Customizable Lightsaber

So I heard you guys want to be a Jedi, This is a color customizable lightsaber that you can make for Halloween or Star Wars event/cosplay

BeginnerFull instructions providedOver 1 day1,879

Things used in this project

Hardware components

Photon
Particle Photon
×1
GY-521 MPU-6050 3 Axis Gyroscope + Accelerometer Module For Arduino
×1
3 watt RGB LED
×1
Jumper wires (generic)
Jumper wires (generic)
×1
1N5333 Diode
×1
Resistor 100 ohm
Resistor 100 ohm
×3
Male Header 40 Position 1 Row (0.1")
Male Header 40 Position 1 Row (0.1")
×1
Female Header 8 Position 1 Row (0.1")
Female Header 8 Position 1 Row (0.1")
×4
SparkFun Male Header 10 Position 1 row (0.1") Right Angle
×1
Li-Ion Battery 1000mAh
Li-Ion Battery 1000mAh
×1

Story

Read more

Schematics

Lightsaber schematics

This is schematics and board for Photon, accelerometer and RGB LED. Been made with EagleCad

LEDsaber schematics (Fritzing)

Code

Ledsaber IntelXDK project 0.1

this is source code of the phone app, developed using IntelSDK

Ledsaber Firmware 0.1

the firmware of Ledsaber project

Credits

Syauqy Nurul Aziz

Syauqy Nurul Aziz

1 project • 2 followers
Hustler by day, Maker by night
Thanks to Farid Inawan and Hanry Ario.
