Things used in this project

Hardware components:
102110017%206
MediaTek Labs LinkIt Smart 7688 Duo
×1
Portlet case
×1
Capacitor 180 uF
×1
Capacitor 10 uF
×1
Capacitor 0.1 uF
×1
Mfr 25frf52 10k sml
Resistor 10k ohm
×1
Mfr 25frf52 1k sml
Resistor 1k ohm
×1
Resistor 255k
×1
Resistor 1.2k
×1
Resistor 8.66k
×1
SparkFun Tactile switch
×1
Reset switch
×1
LT1013
×1
LT1025
×1
SparkFun LCD
×1
SparkFun DIP sockets
×1
Thermocouple socket
×1
MTL Connector
×1
Te connectivity 4 103741 0 image 75px
Male Header 40 Position 1 Row (0.1")
×1
Capacitor 150uF
×1
Capacitor 4.7 uF
×1
Fuse
×1
SparkFun Fuse Clip
×1
Heyco S7560
×1
Outlet Receptacle
×1
Relay
×1
AC-DC Converter
×1
TVS Diode
×1
Thermistor
×1
Fairchild semiconductor pn2222abu. image
General Purpose Transistor NPN
×1
Varistor
×1
Flywheel diode
×1
MTL cable
×1
Super glue
×1
Screws
×1
Software apps and online services:
Ide web
Arduino IDE
Hand tools and fabrication machines:
09507 01
Soldering iron (generic)
Screwdriver
Wire Cutters

Custom parts and enclosures

Portlet Enclosure
If you don't want to purchase and injection molded case, here are the STL files which can be 3D printed for the case enclosure
Bottom enclosure
The bottom half of the Portlet Enclosure in case you would like to 3D print it yourself
Top enclosure
The top half of the Portlet Enclosure for those who want to 3D print it

Schematics

Eagle Files for Linkit Controller board
These files were created in Eagle CAD
linkit_portlet_logic_v1_HO00hQZyfl.zip
Gerber Files for Linkit Controller Board
Gerber files for ordering the board. I would recommend using the provided Eagle files to generate these using whatever settings you are familiar with though.
linkit_portlet_logic_v1_vCO9H7W1mZ.zip
Power Board Eagle files
These are the Eagle CAD files for creating the power board of the Portlet
portlet_1_u7UcJi08cq.zip
Gerber Files for Power Board
These are the Gerber files. I would recommend creating your own Gerbers from the Eagle files to make sure the settings are correct for your board manufacturer
programmable_outlet_power_board_v1_sRDw5zFU5u.zip
Assembly instructions for Linkit Portlet Controller board
Suggested steps and pictures for assembling the Linkit Portlet Controller board
Assembly instructions for Portlet Power board
These instructions are for assembling the Arduino version of the Portlet but the first section covers assembling the Power Board which is the same as for the Linkit version

Code

Project codes for Portlet
Here is a collection of code sets created in the Arduino IDE to control the Portlet for various projects such as making your own yoghurt, brewing beer, a safety device for your soldering iron, etc.
Testing Code
This is my go-to code for making sure all the wiring and functionality in the Portlet is correct

Credits

68af9cf8eb87be31b4e0be7dfc1717d9
Jonathan Thorn

Got frustrated not being able to find exactly what I wanted so started building it myself
