Serial to Ethernet (S2E), StablE

The challenge

CONTEST DEADLINE EXTENDED TO JULY 28TH!

“Serial to Ethernet, StablE" is an international project contest for developers worldwide, powered by WIZnet. This contest gives developers an opportunity to showcase their skills in IoT innovation and competency.

We invite all contestants to explore WIZnet's new serial to Ethernet device, WIZ750SR. Any idea or project submission based on WIZ750SR will be accepted, because every project will enhance the functions of WIZ750SR and empower its usefulness.

For contestants, WIZnet provides the standard firmware which supports configuration of the device by Ethernet and data exchange between serial and Ethernet under plenty of options. Contestants had better use the basic software framework and add only their idea on it. Of course, they can design their own complete code from the beginning just using WIZ750SR as a HW platform. It is recommended to use any kind of sensors, actuators or any other devices additionally to differentiate your project from others.

Start                   Select 200 Ideas & Free Sample(4/23)
[3/16]

Submit your ideas during the first phase of the contest, March 16 - April 20, for a chance to win a free WIZ750SR board to build your project and win cash prizes!

Getting a Time-Limited KEIL uVision5 License:

For participants who need MDK-ARM (KEIL uVision5) development environment, we provide time-limited KEIL license provided by Arm. Please apply through the form below and we will send you a license key after review.

• KEIL uVision5 license request form

Device Overview:

WIZ750SR is a compact sized serial to Ethernet module using the W7500P Ethernet MCU, SoC based on ARM Cortex-M0 architecture. This module product is a protocol converter that transmits data sent by serial equipment as TCP/IP data and converts the TCP/IP data received through the network back into serial data to the serial equipment. It supports all relevant serial interface systems(TTL / RS-232 / RS-422/485). WIZ750SR is the best fit solution to control user's serial device via Ethernet network.

Key Features

• Serial to Ethernet Module based on W7500P MCU

• 10/100Mbps Ethernet & Up to 230kbps serial speed

• Pin-header(2×6) type & RJ-45 connector mounted module

• 4-Pins Configurable User's I/O

• Separate Data UART and Debug UART port

• Configuration is possible via serial AT commands or via Configuration tool

• Support WIZ VSP (Virtual Serial Port) program

• Built-in 10/100Mbps Ethernet ESD Protection IC

WIZ750SR also comes with an evaluation kit and that is known as WIZ750SR-TTL-EVB kit. It consists of WIZ750SR-TTL (3.3V TTL ver.), evaluation board, and cables. This product will help the product design process applying WIZ750SR quickly.

EVB Hardware

• Module Interface (2.54mm Pin Headers, female): 6×2 1EA / 1×6 2EA / 1×2 1EA

• Connectors: Serial Data (D-SUB, 9PIN, Right Angle, Male), Debug USB (Micro USB Type B), 10/100 Ethernet (RJ45)

• Power: 5V DC Jack mounted (External: 4.5Ø, Internal:1.3Ø)

• 4-Push buttons for testing expansion GPIOs (with 1-Potentiometer)

Accessories

• Micro USB Type B Cable (1M)

• UTP LAN Cable (2M)

• Serial Cable

Development Resources:

Visit the following link for product details, datasheet and more information.

• Product Overview

• Getting Started Guide

• User's Manual

• Datasheet

• Software Download

For developers who want to customize WIZ750SR, please refer to the 'Developer's Guide' documents below.

• Building a Development Environment

=> Introduction to how to build a WIZ750SR firmware development environment based on Arm KEIL uvision5 or Eclipse IDE with GNU Arm toolchain.

• Device Recovery Guide

=> Introduction of firmware update method on AppBoot mode using the configuration tool / Firmware restoration method using WIZISP program.

About the Company:

WIZnet is a fabless IT company that provides Internet processors for the IoT. It is the sole innovator to patent the hardwired "TCP/IP" technology into a microprocessor chip in 2001. Since then, a yearly average of 10 million WIZnet chips have been used in various embedded Internet devices worldwide.

Since establishing a loyal brand image with customers, WIZnet cooperates with 70 distributors worldwide with branch offices in USA, China, and Germany for competitive project marketing and faster technical support.

It’s unique technology – "Hardwired TCP/IP" provides better performance and stability than any other software Internet connectivity solutions. We can summarize the main features of Hardwired TCP/IP as Unattackable, High Performance and Easy to Use. It provides "IOcP" and "HW TCP/IP" chips, best fitted for low-end Non-OS devices connecting to the Ethernet for the internet of things.

Click on the following link for more details:

http://www.wiznet.io/

Prizes

First Prize

1 winner

Cash

-

$3,000 value

Most Creative

1 winner

13" MacBook Pro

-

$1,300 value

Best S2E Project

1 winner

iPad Pro

-

$1,200 value

Runner-up

9 winners

Each runner up will receive $500 cash! 9 available

-

$4,500 value
