Ingegno Retro Games Console

Convert an Arduino Nano into a retro games console.

IntermediateFull instructions provided4 hours1,873
Ingegno Retro Games Console

Things used in this project

Hardware components

Arduino Nano R3
Arduino Nano R3
×1
1.8 Inch Color TFT LCD display with MicroSD Card Breakout - ST7735R
×1
Slide Switch
Slide Switch
×1
Pushbutton switch 12mm
SparkFun Pushbutton switch 12mm
×2
joystick
×1
Jumper wires (generic)
Jumper wires (generic)
×1

Software apps and online services

Arduino IDE
Arduino IDE
Blockly4Arduino

Hand tools and fabrication machines

Laser cutter (generic)
Laser cutter (generic)

Story

Read more

Custom parts and enclosures

Lasercut case

Ingegnoretrogame vzztxd7ofp

Schematics

Fritzing schematic Retro Games

image of the wiring

Ingegnoretrogamingwiring bb 6cl7r8vduz

Code

Github

https://github.com/ingegno/RetroGames
