Por la presente, presento un fan que puede controlar de acuerdo a los cambios que ocurren alrededor de su entorno.
Estamos utilizando un sensor LM35 y un controlador de motor STM32_x_nucleo_ihm07m1 para controlar de acuerdo con la temperatura exterior. Cuando la temperatura aumenta, el sensor lo detectará y la velocidad del ventilador estará regulada.
1. Conectando LM35 con placa base
2 . El código
#include <stdio.h>
#include "mbed.h"
#include "RateLimiter.h"
#include "SPN7Driver.h"
// Pin definitions for X-NUCLEO-IHM070M1 with STM32 Nucleo boards
#include "x_nucleo_ihm07m1_targets.h"
// Instance of the motor driver
SPN7Driver M(
P_IN1, P_IN2, P_IN3, // Logic input pins
P_EN1, P_EN2, P_EN3, // Enable channel pins
P_HALL1, P_HALL2, P_HALL3, // Hall sensors pins
P_FAULT // Fault LED
);
// Pin to check temperature on the X-NUCLEO-IHM07M1 board
AnalogIn temperature(P_TEMP);
void checkTemperature()
{
if (temperature > 0.55f){
printf("Overheating... Turning off now\n\r");
M.setDutyCycle(0);
M.coast();
}
}
int main() {
float ca,avg;
int i;
while(1)
{
avg=0;
for(i=0;i<10;i++)
{
a=LM35.read();
avg=avg+(a/10);
wait(.02);
}
c=(avg*3.685503686*100);
wait(1);
// Duty cycle value to be used for speed control
// Positive for clockwise; negative for anti-clockwise
float dc = 0.0f;
Ticker ticker;
ticker.attach(checkTemperature, 1); // Periodic overheating check
while(true) {
if((c >25) && (dc < 0.9f)) {
dc += 0.1f;
M.setDutyCycle(dc);
}
if((c <20) && (dc > -0.9f)) {
dc -= 0.1f;
M.setDutyCycle(dc);
}
printf("Duty Cycle: %1.2f, Sector: %d\n\r",dc, M.getSector());
}
}
/* mbed Microcontroller Library
* Copyright (c) 2006-2016 ARM Limited
*
* Licensed under the Apache License, Version 2.0 (the "License");
* you may not use this file except in compliance with the License.
* You may obtain a copy of the License at
*
* http://www.apache.org/licenses/LICENSE-2.0
*
* Unless required by applicable law or agreed to in writing, software
* distributed under the License is distributed on an "AS IS" BASIS,
* WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
* See the License for the specific language governing permissions and
* limitations under the License.
*/
/**
******************************************************************************
* @file SPN7Driver.h
* @author STMicroelectronics
* @brief Header file for SPN7Driver based on BLDCmotorDriver class
******************************************************************************
* @copy
*
* THE PRESENT FIRMWARE WHICH IS FOR GUIDANCE ONLY AIMS AT PROVIDING CUSTOMERS
* WITH CODING INFORMATION REGARDING THEIR PRODUCTS IN ORDER FOR THEM TO SAVE
* TIME. AS A RESULT, STMICROELECTRONICS SHALL NOT BE HELD LIABLE FOR ANY
* DIRECT, INDIRECT OR CONSEQUENTIAL DAMAGES WITH RESPECT TO ANY CLAIMS ARISING
* FROM THE CONTENT OF SUCH FIRMWARE AND/OR THE USE MADE BY CUSTOMERS OF THE
* CODING INFORMATION CONTAINED HEREIN IN CONNECTION WITH THEIR PRODUCTS.
*
* <h2><center>© COPYRIGHT 2016 STMicroelectronics</center></h2>
*/
// This example is based on the BLDCmotorDriver motor control library
// by the TVZ Mechatronics Team, University of Applied Sciences Zagreb,
// Professional Study in Mechatronics:
// https://developer.mbed.org/teams/TVZ-Mechatronics-Team/code/BLDCmotorDriver/
#ifndef __SPN7DRIVER_H__
#define __SPN7DRIVER_H__
#include "mbed.h"
#include "BLDCmotorDriver.h"
class SPN7Driver : public BLDCmotorDriver {
public:
SPN7Driver(PinName pIN1, PinName pIN2, PinName pIN3,
PinName pEN1, PinName pEN2, PinName pEN3,
PinName pH1, PinName pH2, PinName pH3,
PinName pFault);
void setDutyCycle(float dutyCycle);
protected:
void commutation();
};
#endif // __SPN7DRIVER_H__
/* mbed Microcontroller Library
* Copyright (c) 2006-2016 ARM Limited
*
* Licensed under the Apache License, Version 2.0 (the "License");
* you may not use this file except in compliance with the License.
* You may obtain a copy of the License at
*
* http://www.apache.org/licenses/LICENSE-2.0
*
* Unless required by applicable law or agreed to in writing, software
* distributed under the License is distributed on an "AS IS" BASIS,
* WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
* See the License for the specific language governing permissions and
* limitations under the License.
*/
/**
******************************************************************************
* @file SPN7Driver.cpp
* @author STMicroelectronics
* @brief Implementation of SPN7Driver class
******************************************************************************
* @copy
*
* THE PRESENT FIRMWARE WHICH IS FOR GUIDANCE ONLY AIMS AT PROVIDING CUSTOMERS
* WITH CODING INFORMATION REGARDING THEIR PRODUCTS IN ORDER FOR THEM TO SAVE
* TIME. AS A RESULT, STMICROELECTRONICS SHALL NOT BE HELD LIABLE FOR ANY
* DIRECT, INDIRECT OR CONSEQUENTIAL DAMAGES WITH RESPECT TO ANY CLAIMS ARISING
* FROM THE CONTENT OF SUCH FIRMWARE AND/OR THE USE MADE BY CUSTOMERS OF THE
* CODING INFORMATION CONTAINED HEREIN IN CONNECTION WITH THEIR PRODUCTS.
*
* <h2><center>© COPYRIGHT 2016 STMicroelectronics</center></h2>
*/
// This example is based on the BLDCmotorDriver motor control library
// by the TVZ Mechatronics Team, University of Applied Sciences Zagreb,
// Professional Study in Mechatronics:
// https://developer.mbed.org/teams/TVZ-Mechatronics-Team/code/BLDCmotorDriver/
#include "mbed.h"
#include "SPN7Driver.h"
typedef enum {
ST_BLDC_LOW = 0,
ST_BLDC_HIGH,
ST_BLDC_OFF
} st_bldc_status_t;
/**************************************************************************/
/**
@brief Constructor
* @param pIN1 Logic input pin IN1 of L6230 chip
* @param pIN2 Logic input pin IN2 of L6230 chip
* @param pIN3 Logic input pin IN3 of L6230 chip
* @param pEN1 Enable channel pin EN1 of L6230 chip
* @param pEN2 Enable channel pin EN2 of L6230 chip
* @param pEN3 Enable channel pin EN3 of L6230 chip
* @param pH1 Hall sensor pin for phase #1 (A) of X-NUCLEO-IHM07M1
* @param pH2 Hall sensor pin for phase #2 (B) of X-NUCLEO-IHM07M1
* @param pH3 Hall sensor pin for phase #3 (Z) of X-NUCLEO-IHM07M1
* @param pFault Fault LED pin of X-NUCLEO-IHM07M1
*/
/**************************************************************************/
SPN7Driver::SPN7Driver(PinName pIN1, PinName pIN2, PinName pIN3,
PinName pEN1, PinName pEN2, PinName pEN3,
PinName pH1, PinName pH2, PinName pH3,
PinName pFault) :
BLDCmotorDriver(pIN1, pIN2, pIN3,
pEN1, pEN2, pEN3,
pH1, pH2, pH3,
pFault)
{
// The BLDCmotorDriver class was implemented for half-bridge drivers
// so the pin names may be misleading when referring to the L6230 chip.
// Get pointers to each input pin and call them IN[x] (logic input)
// to be consistent with the terminology used in the L6230 documentation.
PwmOut* IN[3] = {&GH_A, &GH_B, &GH_C};
// Set the switching period of the INx logic input pins (PWM driven)
for (int i = 0; i < 3; i++) {
IN[i]->period(switchingPeriod);
}
// Set the step commutation function (triggered by the Hall sensors)
H1.rise(this, &SPN7Driver::commutation);
H2.rise(this, &SPN7Driver::commutation);
H3.rise(this, &SPN7Driver::commutation);
H1.fall(this, &SPN7Driver::commutation);
H2.fall(this, &SPN7Driver::commutation);
H3.fall(this, &SPN7Driver::commutation);
}
/**************************************************************************/
/**
@brief Set duty cycle for motor control
* @param dc duty cycle value (>0 clockwise; <0 anti-clockwise)
*/
/**************************************************************************/
void SPN7Driver::setDutyCycle(float dc) {
if (dc >= -1 && dc <= 1) {
ticker.attach(this, &SPN7Driver::commutation, sampleTime);
tempDutyCycle = dc;
} else {
coast();
}
}
// six-step phase commutation
void SPN7Driver::commutation()
{
// The BLDCmotorDriver class was implemented for half-bridge drivers
// so the pin names may be misleading when referring to the L6230 chip.
// Get pointers to each input pin and call them IN[x] (logic input)
// to be consistent with the terminology used in the L6230 documentation.
PwmOut* IN[3] = {&GH_A, &GH_B, &GH_C};
// Get pointers to each enable pin and call them ENx (enable channel)
// to be consistent with the terminology used in the L6230 documentation.
DigitalOut* EN[3] = {&GL_A, &GL_B, &GL_C};
st_bldc_status_t tab[6][3] = {
{ST_BLDC_OFF, ST_BLDC_LOW, ST_BLDC_HIGH},
{ST_BLDC_HIGH, ST_BLDC_LOW, ST_BLDC_OFF},
{ST_BLDC_HIGH, ST_BLDC_OFF, ST_BLDC_LOW},
{ST_BLDC_OFF, ST_BLDC_HIGH, ST_BLDC_LOW},
{ST_BLDC_LOW, ST_BLDC_HIGH, ST_BLDC_OFF},
{ST_BLDC_LOW, ST_BLDC_OFF, ST_BLDC_HIGH},
};
dutyCycle = rl.out(tempDutyCycle);
int sector = getSector();
if (dutyCycle == 0) {
// Stop the motor
coast();
return;
}
// Move to next sector (i.e. commute phase)
if (dutyCycle > 0 ) {
// Clockwise spinning
// The rows of the phase status table are offset by one when spinning
// clockwise so we need to increment the current sector by two steps
sector = (sector + 2) % 6;
} else {
// Anti-clockwise spinning
sector--;
if(sector < 0) sector = 5;
}
// Get the absolute value of the duty cycle for the PWM
float d = (dutyCycle > 0) ? dutyCycle : -dutyCycle;
// Update the logic inputs and the enable pins
for (int i = 0; i < 3; i++) {
*EN[i] = (tab[sector][i] == ST_BLDC_OFF) ? 0 : 1;
*IN[i] = (tab[sector][i] == ST_BLDC_HIGH) ? d : 0;
}
}
