Arduino Telegraph

//  Needs Fifo.h (Queue functions) copied into the sketch folder
#include "Fifo.h"
Fifo<char> symbolQueue( 160 )  ;

const uint8_t led = 2;
const uint8_t ledPin = 3;
const uint8_t buz = 4;
const uint8_t buzPin = 5;
const int inputPin = 6;

String code = "";

// To increase speed, change '50' to a smaller number..
// To decrease speed, change '50' to a larger number..
const unsigned long  MsecDot   = 50;
const unsigned long  MsecDash  = MsecDot * 3;
const unsigned long  MsecSym   = MsecDot;
const unsigned long  MsecLtr   = MsecDot * 3;
const unsigned long  MsecWord  = MsecDot * 7;

String letters[] = {".-", "-...", "-.-.", "-..", ".", "..-.", "--.", "....", "..", ".---", "-.-", ".-..", "--", "-.", "---", ".--.", "--.-",
                    ".-.", "...", "-", "..-", "...-", ".--", "-..-", "-.--", "--..",
                    "-----"  , ".----"  , "..---"  , "...--"  , "....-" , "....." , "-...."  , "--..." , "---.." , "----." , "E"  };// Morse letters (26) followed by numbers(10)

void convertor(){

  int i = 0;
  if (code == ".-.-.-")
  {
    Serial.print(".");
  }
  else
  {
    while (letters[i] != "E")
    {
      if (letters[i] == code)
      {
        if ( i >= 0 && i <= 25 ) Serial.print(char('A' + i));
        else if ( i >= 26 && i <= 35 ) Serial.print(char('0' + i - 26 ));
        break;
      }
      i++;
    }
    if (letters[i] == "E")
    {
      Serial.println("");
    }
  }
  code = "";
}

bool  getKey() {
  // get debounced key press
  static bool currentKeyState = HIGH ;
  static bool newKeyState = HIGH ;
  static uint32_t newKeyStateAtMs = millis()  ;

  bool dr =  digitalRead(inputPin) ;
  if ( dr != newKeyState ) {
    newKeyState = dr ;
    newKeyStateAtMs = millis() ;
  }
  if ( currentKeyState != newKeyState && millis() - newKeyStateAtMs > 25 ) {
    // debounce: accept only a mature change ( > X ms )
    currentKeyState = newKeyState ;
  }
  return currentKeyState ;
}

void decoder() {

  static bool lastKey = HIGH ;
  static uint32_t lastTranstionAtMs = millis() ;
  static bool inLetter = false ;
  static bool inWord = false ;

  uint32_t ms = millis() ;

  digitalWrite( ledPin, !getKey() ) ;
  digitalWrite( buzPin, !getKey() ) ;

  if ( getKey() != lastKey ) {
    // transition
    if ( lastKey == LOW ) {
      // we were in a symbol - determine if it was a '.' or a '-'
      code += ( ms - lastTranstionAtMs < MsecDot * 2 ? '.' : '-' ) ;
    }  else {
      // we were in a space
      inLetter = true ;
      inWord = true ;
    }
    lastTranstionAtMs = ms ;
    lastKey = getKey() ;
  }

  if ( getKey() == HIGH ) {
    // we are in a space
    if ( inLetter && ms - lastTranstionAtMs > MsecLtr ) {
      // flush out letter
      convertor() ;
      inLetter = false ;
    }
    if ( inWord && ms - lastTranstionAtMs > MsecWord ) {
      // flush out word
      Serial.print(" " ) ;
      inWord = false ;
    }
  }
}

void charToMorse( char mChar ) {
  // converts input character to a set of morse symbols which are pushed onto a
  // queue together with an end of character marker '|'

  uint8_t offset ;   // offset into table letters[] based on ascii code of char
  bool inTable = false ;

  if ( mChar >= 'a' && mChar <= 'z' ) {
    offset = mChar - 97 ;
    inTable = true ;
  }
  else if ( mChar >= 'A' && mChar <= 'Z' ) {
    offset = mChar - 64 ;
    inTable = true ;
  }
  else if ( mChar >= '0' && mChar <= '9' ) {
    offset = (mChar - 48) + 26 ;
    inTable = true ;
  }
  else {}

  if ( inTable ) {
   // Serial.print( letters[ offset ] ) ;
    for ( uint8_t i = 0 ; i < letters[ offset ].length() ; i++ ) symbolQueue.push( letters[ offset ].charAt( i )   ) ;
    symbolQueue.push( '|' ) ;
  }
  else if ( mChar == ' ' ) {
    // Serial.print( '|' ) ;
    symbolQueue.push( '|' ) ;
  }
}

void setup() {
  Serial.begin(9600);
  pinMode(led, OUTPUT);
  pinMode(ledPin, OUTPUT);
  pinMode(buz, OUTPUT);
  pinMode(buzPin, OUTPUT);
  pinMode(inputPin, INPUT_PULLUP);
  Serial.println("Start");
  symbolQueue.flush() ;
}

void loop() {
  enum state_t { inDot, inDash, inSpace, inWaiting } ;
  static state_t state = inWaiting ;
  static uint32_t inStateAtMs = millis() ;

  // get input from user, analyse, convert to morse symbols and queue
  if (Serial.available()) {
    char inChar = Serial.read() ;
    charToMorse( inChar ) ;
  }

  // finite state machine - unload queue and sound buzzer as required

  switch ( state ) {

    case inWaiting : {
        if ( ! symbolQueue.isempty() ) {
          char inCh = symbolQueue.pop() ;
          // debug
          Serial.print( inCh ) ;

          inStateAtMs = millis() ;
          if ( inCh == '.' ) {
            digitalWrite(led, HIGH);
            digitalWrite(buz, HIGH);
            state = inDot ;
          }
          else if ( inCh == '-' ) {
            digitalWrite(led, HIGH);
            digitalWrite(buz, HIGH);
            state = inDash ;
          }
          else if ( inCh == '|' ) {
            state = inSpace ;
          }
        }
        break ;
      }

    case inDot : {
        if ( millis() - inStateAtMs > MsecDot ) {
          inStateAtMs = millis() ;
          digitalWrite(led, LOW);
          digitalWrite(buz, LOW);
          state = inSpace ;
        }
        break ;
      }

    case inDash : {
        if ( millis() - inStateAtMs > MsecDash  ) {
          inStateAtMs = millis() ;
          digitalWrite(led, LOW);
          digitalWrite(buz, LOW);
          state = inSpace ;
        }
        break ;
      }

    case inSpace : {
        if ( millis() - inStateAtMs > MsecLtr  ) {
          inStateAtMs = millis() ;
          digitalWrite(led, LOW);
          digitalWrite(buz, LOW);
          state = inWaiting ;
        }
        break ;
      }
  }

  decoder() ;
}
