KitchenHelper-This is a visual timer controlled by voice.

#include <Arduino.h>
#ifdef ESP32
#include <WiFi.h>
#else
#include "ESP8266WiFi.h"        // 本程序使用 ESP8266WiFi库
#endif

#include <DHT.h>                //引入DHT11库
#include <ESP8266WebServer.h>   //  ESP8266WebServer库
#include <WiFiClient.h>
#include <WiFiUdp.h>
#include <NTPClient.h>
#include <EEPROM.h>
#include <FastLED.h>
#include <Ticker.h>
#include <PubSubClient.h>
#include <ESP8266HTTPClient.h>
#include <ArduinoJson.h>
#include <ArduinoOTA.h>
#include "config.h"

int otaFlag=0;                        //0:普通工作模式，1：刷机模式
bool otaInProgress = false;

String devwxid="";
String deviceId="";
String deviceType="0";
String wifiSetting = "0";             //0代表未完成,1代表完成

const char *pubTOPIC = "pub_topic_mqtt";

int recCount=0;
unsigned char recBuffer[5];           //定义串口接收数组
WiFiClient espClient;
PubSubClient mqttClient(espClient);

CRGB leds[NUM_LEDS];              //建立光带leds
//CHSV timerHSVColor(39,255,50);   //HSV方法定义计时器显示颜色timerHSVColor(色调，饱和度，亮度)
int curColor;
uint32_t curDelay;

Ticker ledActionTimer;

WiFiUDP ntpUDP;          //创建UDP实例
NTPClient timeClient(ntpUDP, "pool.ntp.org");

//Last time when the LEDs were updated
bool needTo_sendDHT=false;
DHT dhtSensor(DHT_DATA_PIN,DHTTYPE);
float sensor_hum;
float sensor_tem;

Ticker delayTimer;

//定义闪存WIFI信息结构体
struct config_type{
  char stassid[32];
  char stapsw[64];
  char devid[16];
  char curMode[16];
};
config_type devConfig;

int clockCount;
Ticker clockTicker;  //每隔1分钟采集一次网络时间

int dhtCount;
Ticker dhtTicker;

Ticker ringTimer;               //定义铃声
int ringCount = 0;              //定义播放次数计数器

int input1Time=0;               //定义第一面的计时秒数
int input2Time=0;               //定义第二面的计时秒数
int lightUpInterval=0;          //定义循环时间
int lightsOff=NUM_LEDS-1;       //要熄灭的led灯
int timerCount=0;
Ticker timerTicker;

uint32_t timesTotal=0;
bool timerFlag=false;             //计时标志
Ticker totalTimerTicker;          //秒数计时

ESP8266WebServer esp8266_server(80);  // 建立ESP8266WebServer对象，对象名称为esp8266_server

void setup(){
  //设置串口波特率，以便打印信息
  Serial.begin(9600);
  while(Serial.read()>= 0) {}   //清除串口缓存
  //Serial1.begin(115200);

  // INIT LED
  FastLED.addLeds<LED_TYPE, LED_DATA_PIN, COLOR_ORDER>(leds, NUM_LEDS);   // 光带初始化WS2812B (Neopixel)
  FastLED.setMaxPowerInVoltsAndMilliamps(5, 100);                         //电源管理:设置最大电压（5v）和最大电流（500mA），让不会消耗Arduino太大电流。
  FastLED.setBrightness(max_bright);                                      // 设置光带亮度
  FastLED.clear();
  FastLED.show();
  delay(100);
  loadConfig();        //获取ESP8266闪存数据
  if (strcmp(devConfig.curMode, "") == 0) {
    //Serial1.println("当前为离线模式WIFI未设置");
    VoicePlay(0x05,0,0);            //发送语音告知
    delay(2000);
    //curRGBColor.r=0;
    //curRGBColor.g=0;
    //curRGBColor.b=255;
    //leds[0]=CRGB::Red;             //熄灭最后一盏灯
    //leds[11]=CRGB::Green;             //熄灭最后一盏灯
    //leds[2]=CRGB::Blue;             //熄灭最后一盏灯
    //FastLED.show();
    for (int i=0;i<3;i++) {
      fill_solid(leds, NUM_LEDS,CRGB::Red);
      FastLED.show();
      delay(500);
      fill_solid(leds, NUM_LEDS,CRGB::Black);
      FastLED.show();
      delay(500);
    }
  }

  if (strcmp(devConfig.curMode, "1") == 0) {
    connectWiFi();
    if (WiFi.status() == WL_CONNECTED) {
      Serial1.println(F("WIFI IS SUCCESSED..."));
      VoicePlay(0x06,0,0);            //发送在线语音告知

      ledOff();

      for (int i=0;i<3;i++) {
        fill_solid(leds, NUM_LEDS,CRGB::Green);
        FastLED.show();
        delay(500);
        fill_solid(leds, NUM_LEDS,CRGB::Black);
        FastLED.show();
        delay(500);
      }

      // INIT OTA
      ArduinoOTA.setHostname(ESP_NAME);
      ArduinoOTA.onStart([]() {
      otaInProgress = true;
        Serial.println(F("Start updating..."));
      });
      ArduinoOTA.onProgress([](unsigned int progress, unsigned int total) {
        Serial.println(progress / (total / 100));
      });
      ArduinoOTA.onEnd([]() {
        Serial.println(F("\nend"));
        otaInProgress = false;
      });
      ArduinoOTA.onError([](ota_error_t error) {
      String msg;
      if (error == OTA_AUTH_ERROR)
        msg = F("auth failed");
      else if (error == OTA_BEGIN_ERROR)
        msg = F("begin failed");
      else if (error == OTA_CONNECT_ERROR)
        msg = F("connect failed");
      else if (error == OTA_RECEIVE_ERROR)
        msg = F("receive failed");
      else if (error == OTA_END_ERROR)
        msg = F("end failed");
        Serial.printf_P(PSTR("Error: %s"), msg.c_str());
      });
      ArduinoOTA.begin();


      //初始化ONENET通信,客户端设置MQTT服务器 & 回调函数
      mqttClient.setServer(MQTT_SERVER, MQTT_PORT);
      mqttClient.setCallback(mqttCallback);
      //mqttClient.setBufferSize(MQTT_BUFF_SIZE);
      mqttConnect();
      delay(300);

      // CLOCK
      timeClient.begin();
      timeClient.setTimeOffset(28800);
      getNtpTime();

      clockTicker.attach(1,tickerClockCount);
      delay(50);
    }
  }

  if (strcmp(devConfig.curMode, "2") == 0) {
    initWiFi();        //进入配网函数
  }

  FastLED.clear();
  FastLED.show();
  delay(100);

  //DHT
  dhtSensor.begin();
  getDHTdata();
  dhtTicker.attach(1, tickerDhtCount);
}

void loop()
{
  unsigned long curMillis = millis();             //获取当前系统时间

  // put your main code here, to run repeatedly:
  getSerialData();
  if (recCount==5) {                      //串口数据包长度正确
    recCount=0;
    if ((recBuffer[0]==0xAA) && (recBuffer[1]==0x55) && (recBuffer[3]==0x55) && (recBuffer[4]==0xAA)) {
      unsigned char cmdUart=recBuffer[2];
      switch (cmdUart) {
        case 0xB8:                          //8分熟牛排
          led1Default();                    //led计时初始化
          input1Time=60;                    //第一面定义60秒计时
          input2Time=90;                    //第二面定义90秒计时
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                 //设置每隔1秒触发一次tickerTimerCount函数
          break;
        case 0xB5:                          //5分熟牛排
          led1Default();
          input1Time=40;                    //第一面定义40秒计时
          input2Time=60;                    //第二面定义60秒计时
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                 //设置每隔1秒触发一次tickerTimerCount函数
          break;
        case 0xBF:                          //全熟牛排
          led1Default();
          input1Time=60;                    //第一面定义60秒计时
          input2Time=120;                   //第二面定义120秒计时
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                 //设置每隔1秒触发一次tickerTimerCount函数
          break;
        case 0xD8:                            //清蒸大闸蟹
          led1Default();                      //led计时初始化
          input1Time=1320;                    //冷水大火蒸22分钟计时
          input2Time=300;                     //关火后焖5分钟计时
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                 //设置每隔1秒触发一次tickerTimerCount函数
          break;

        case 0xF0:                          //调亮一点
          max_bright=max_bright+1;
          FastLED.setBrightness(max_bright);
          break;
        case 0xF1:                          //调暗一点
          max_bright=max_bright-1;
          if (max_bright <= 0){
            max_bright=0;
          }
          FastLED.setBrightness(max_bright);
          break;

        case 0xFE:                          //启动WIFI配置模式
          restoreFactory(true);
          break;
        case 0xFF:                          //恢复初始设置
          delay(3000);
          restoreFactory(false);
          break;

        case 0xDD:                          //切换到时钟模式
          //timerTicker.detach();
          Serial.println(F("switch NETWORK TIME... \n"));
          //delay(2000);
          //VoicePlay(0x01,0,0);
          break;
        case 0xEE:                          //取消计时|停止计时
          ledOff();

          ringTimer.detach();

          input1Time=0;
          input2Time=0;
          if (timerFlag == true)  {           //时间计时中
            totalTimerTicker.detach();
            int mHours, mMinutes, mSeconds;
            convertSecondsToTime(timesTotal, mHours, mMinutes, mSeconds);
            VoicePlay(0x0E,mHours,0);
            delay(10);
            VoicePlay(0x0F,mMinutes,0);
            delay(20);
            VoicePlay(0x10,mSeconds,0);
            timesTotal=0;
          }
          else  {
            VoicePlay(0x01,0,0);
          }
          timerFlag=false;
          break;

        case 0xD0:                          //三十秒计时
          led1Default();
          input1Time=30;
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                 //设置每隔1秒触发一次tickerTimerCount函数
          //Serial.println("30s start()........");
          break;
        case 0xD1:                          //四十秒计时
          led1Default();
          input1Time=40;
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                //设置每隔1秒触发一次tickerTimerCount函数
          break;
        case 0xD2:                          //五十秒计时
          led1Default();
          input1Time=50;
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);      //设置每隔1秒触发一次tickerTimerCount函数
          break;
        case 0xD3:                          //一分钟钟计时
          led1Default();
          input1Time=60;
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                 //设置每隔1秒触发一次tickerTimerCount函数
          break;
        case 0xD4:                          //一分半计时
          led1Default();
          input1Time=90;
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                //设置每隔1秒触发一次tickerTimerCount函数
          break;
        case 0xD5:                          //两分钟计时
          led1Default();
          input1Time=120;                  //定义120秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                 //设置每隔1秒触发一次tickerTimerCount函数
          break;
        case 0xD6:                          //两分半计时
          led1Default();
          input1Time=150;                  //定义150秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                 //设置每隔1秒触发一次tickerTimerCount函数
          break;
        case 0xD7:                          //三分计时
          led1Default();
          input1Time=180;                  //定义180秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                //设置每隔1秒触发一次tickerTimerCount函数
          break;
        case 0xC4:                          //四分计时
          led1Default();
          input1Time=240;                  //定义320秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                 //设置每隔1秒触发一次tickerTimerCount函数
          break;
        case 0xC5:                          //五分计时
          led1Default();
          input1Time=300;                  //定义300秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);                 //设置每隔1秒触发一次tickerTimerCount函数
          break;
        case 0xC6:                          //六分计时
          led1Default();
          input1Time=360;                  //定义360秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xC7:                          //七分计时
          led1Default();
          input1Time=420;                  //定义420秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xC8:                          //八分计时
          led1Default();
          input1Time=480;                  //定义480秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xC9:                          //九分计时
          led1Default();
          input1Time=540;                  //定义540秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xA1:                          //十分钟计时
          led1Default();
          input1Time=600;                  //定义600秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;

        case 0xA2:                          //十五分钟计时
          led1Default();
          input1Time=900;                  //定义900秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xA3:                          //二十分钟计时
          led1Default();
          input1Time=1200;                  //定义1200秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xA6:                          //二十五分钟计时
          led1Default();
          input1Time=1500;                  //定义1500秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xA4:                          //三十分钟计时
          led1Default();
          input1Time=1800;                  //定义1800秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xA7:                          //三十五分钟计时
          led1Default();
          input1Time=2100;                  //定义2100秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xA8:                          //四十分钟计时
          led1Default();
          input1Time=2400;                  //定义2400秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xB6:                          //四十五分钟计时
          led1Default();
          input1Time=2700;                  //定义2700秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xB7:                          //五十分钟计时
          led1Default();
          input1Time=3000;                  //定义3000秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xA5:                          //一小时计时
          led1Default();
          input1Time=3600;                  //定义3600秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xC3:                          //一个半小时计时
          led1Default();
          input1Time=5400;                  //定义5400秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xC2:                          //两小时计时
          led1Default();
          input1Time=7200;                  //定义7200秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;
        case 0xC1:                          //两小时半计时
          led1Default();
          input1Time=9000;                  //定义9000秒计时
          input2Time=0;
          lightUpInterval=(int) (input1Time / NUM_LEDS);
          timerTicker.attach(1, tickerTimerCount);
          break;

        case 0xB1:                          //开始计时
          ledOff();
          timesTotal=0;
          timerFlag=true;                   //计时标志
          totalTimerTicker.attach(1,gatherTimesTicker);                 //设置每隔1秒触发一次gatherTimesTicker计时函数
          break;

        default:
          break;
      }
    }
  }

  if (input1Time > 0) {                  //A面计时
    if (timerCount >= input1Time ) {
      timerTicker.detach();

      ledOff();
      input1Time=0;
      timerCount=0;

      if (input2Time>0) {
        switch (input2Time) {
          case 60:
            VoicePlay(0x09,0,0);            //计时开始，发送语音告知
            break;
          case 90:
            VoicePlay(0x0A,0,0);            //计时开始，发送语音告知
            break;
          case 120:
            VoicePlay(0x0B,0,0);            //计时开始，发送语音告知
            break;
          case 300:
            VoicePlay(0x07,0,0);            //蒸后关火焖计时开始，发送语音告知
            break;
          default:
            VoicePlay(0x08,0,0);              //A面完成语音告知
            break;
        }

        led2Default();

        lightUpInterval=(int) (input2Time / NUM_LEDS);
        timerTicker.attach(1, tickerTimerCount);                //设置每隔1秒触发一次tickerTimerCount函数
      }
      else{
        VoicePlay(0x01,0,0);
        dhtTicker.attach(1, tickerDhtCount);
        clockTicker.attach(1,tickerClockCount);
        //delay(50);
        //ledOff();                         //再刷新一次
      }
    }
  }

  if ((input2Time > 0) && (input1Time == 0)) {                  //B面计时
    if (timerCount >= input2Time) {      // 当到达计时时间时
      timerTicker.detach();              //关闭定时器
      ledOff();                          //熄灭最后一盏灯

      timerCount = 0;
      input2Time=0;
      input1Time=0;
      VoicePlay(0x01,0,0);              //B面完成语音告知

      dhtTicker.attach(1, tickerDhtCount);
      clockTicker.attach(1,tickerClockCount);
    }
  }

  if (timerFlag){           //正在计时中......
    //ppLed();
    timerLed();
  }

  if ((input1Time ==0 ) && (input2Time ==0)) {
    //每隔2分钟DHT采集一次数据
    if (dhtCount >= 120)  {
      //Serial.println("开始采集DHT信息... \n");
      getDHTdata();
      dhtCount=0;
    }

    bool wifiIsConnected = WiFi.isConnected();
    if (wifiIsConnected){
      //check OTA update progress
      if (otaFlag ==  1) {
        ArduinoOTA.handle();
        if (otaInProgress) {
            return;
        }
      }

      // put your main code here, to run repeatedly:
      //每隔1分钟采集一次网络时间数据
      if (clockCount  >= 60) {
        clockCount=0;
        getNtpTime();
      }

      // HANDLE MQTT
      static unsigned long lastMqttConnMillis = 0;
      //Serial1.println("HANDLE MQTT....");
      if (!mqttClient.connected()) {
        Serial1.println(F("当前MQTT未连接"));
        if (curMillis - lastMqttConnMillis > 3000) {
          Serial1.println(F("Disconnected from MQTT"));
          mqttConnect();
          lastMqttConnMillis = curMillis;
        }
      }
      else {
        mqttClient.loop();

        if(needTo_sendDHT)  {
          //MQTT发送数据
          //String dhtData ="温度："+String(sensor_tem) +"℃"+","+"湿度："+ String(sensor_hum)+"%" ; //生成要传输的数据
          //strcpy(c_DHT,dhtData.c_str());
          sendDHTdata();
          delay(100);
        }
      }
    }
  }
  delay(50);
  FastLED.show();
   // 释放内存
  //freeRam();
}
