This app is designed to send a notification to a user on their Qualcomm Toq watch if they are within 50 meters of Lower Sproul located at the UC Berkeley campus. This person receives a notification to draw an image based on a random card that has been installed on the Toq device. This enables a DrawingView where the user can paint on the screen with various paint colors, brush sizes, options for erasing, starting over, and saving the drawing to the gallery. The user is then able to upload the image to Flickr with the {cs160fsm} tag. An image is then downloaded from Flickr and re-sized to fit the Toq screen and added to the end of the list of the users current cards.
http://www.youtube.com/watch?v=4pzu1s4Gn5M&feature=youtu.be
MainActivity.java
JavaMain Activity code for FSM watch. In hindsight, most of this code can be removed from the Main Activity.
package com.example.cshort.drawingapplication;
import android.app.Activity;
import android.app.AlertDialog;
import android.app.Dialog;
import android.content.Context;
import android.content.DialogInterface;
import android.content.Intent;
import android.database.Cursor;
import android.graphics.Bitmap;
import android.graphics.BitmapFactory;
import android.location.Location;
import android.location.LocationListener;
import android.location.LocationManager;
import android.net.Uri;
import android.os.Bundle;
import android.provider.MediaStore;
import android.view.Menu;
import android.view.MenuItem;
import android.view.View;
import android.widget.ImageButton;
import android.widget.LinearLayout;
import android.widget.Toast;
import com.gmail.yuyang226.flickrj.sample.android.FlickrHelper;
import com.gmail.yuyang226.flickrj.sample.android.FlickrjActivity;
import com.googlecode.flickrjandroid.Flickr;
import com.googlecode.flickrjandroid.FlickrException;
import com.googlecode.flickrjandroid.REST;
import com.googlecode.flickrjandroid.photos.Photo;
import com.googlecode.flickrjandroid.photos.PhotoList;
import com.googlecode.flickrjandroid.photos.PhotosInterface;
import com.googlecode.flickrjandroid.photos.SearchParameters;
import com.qualcomm.toq.smartwatch.api.v1.deckofcards.DeckOfCardsEventListener;
import com.qualcomm.toq.smartwatch.api.v1.deckofcards.card.Card;
import com.qualcomm.toq.smartwatch.api.v1.deckofcards.card.ListCard;
import com.qualcomm.toq.smartwatch.api.v1.deckofcards.card.NotificationTextCard;
import com.qualcomm.toq.smartwatch.api.v1.deckofcards.card.SimpleTextCard;
import com.qualcomm.toq.smartwatch.api.v1.deckofcards.remote.DeckOfCardsManager;
import com.qualcomm.toq.smartwatch.api.v1.deckofcards.remote.RemoteDeckOfCards;
import com.qualcomm.toq.smartwatch.api.v1.deckofcards.remote.RemoteDeckOfCardsException;
import com.qualcomm.toq.smartwatch.api.v1.deckofcards.remote.RemoteResourceStore;
import com.qualcomm.toq.smartwatch.api.v1.deckofcards.remote.RemoteToqNotification;
import com.qualcomm.toq.smartwatch.api.v1.deckofcards.resource.CardImage;
import org.json.JSONException;
import java.io.File;
import java.io.IOException;
import java.io.InputStream;
import java.util.Iterator;
import java.util.Random;
import java.util.UUID;
import javax.xml.parsers.ParserConfigurationException;
public class MainActivity extends Activity {
private DeckOfCardsManager deckOfCardsManager;
private DeckOfCardsEventListener deckOfCardsEventListener;
private RemoteDeckOfCards remoteDeckOfCards;
private RemoteResourceStore remoteResourceStore;
private SimpleTextCard simpleTextCard;
private ListCard listCard;
private CardImage[] cardImages;
private String notificationCardSent;
private final int WIDTH = 250;
private final int HEIGHT = 288;
protected File fileUri;
private Location destination;
private DrawingView drawView;
private ImageButton currPaint, drawBtn, eraseBtn, newBtn, saveBtn;
private float smallBrush, mediumBrush, largeBrush;
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);
// Get the reference to the deck of cards manager
deckOfCardsManager = DeckOfCardsManager.getInstance(getApplicationContext());
deckOfCardsEventListener = new mDeckOfCardsEventListener();
init();
initLocation();
initDrawing();
}
// Initialize remoteResourceStore, get the card images for cardImages[]
// and create a remoteDeckOfCards.
public void init() {
// Creates a resource storage for card icons
remoteResourceStore = new RemoteResourceStore();
// Get the card images
try {
cardImages = new CardImage[10];
cardImages[0] = new CardImage("card.image.1", getBitmap("art_goldberg_toq.png"));
cardImages[1] = new CardImage("card.image.2", getBitmap("jack_weinberg_toq.png"));
cardImages[2] = new CardImage("card.image.3", getBitmap("jackie_goldberg_toq.png"));
cardImages[3] = new CardImage("card.image.4", getBitmap("joan_baez_toq.png"));
cardImages[4] = new CardImage("card.image.5", getBitmap("mario_savio_toq.png"));
cardImages[5] = new CardImage("card.image.6", getBitmap("michael_rossman_toq.png"));
}
catch (Exception e) {
Toast.makeText(this, "Error occurred retrieving card images", Toast.LENGTH_SHORT).show();
return;
}
try {
remoteDeckOfCards = createDeckOfCards();
}
catch (Throwable e) {
e.printStackTrace();
}
// Re-populate the resource store with any card images being used by any of the cards
for (Iterator<Card> it = remoteDeckOfCards.getListCard().iterator(); it.hasNext(); ) {
String cardImageId = ((SimpleTextCard) it.next()).getCardImageId();
if ((cardImageId != null) && !remoteResourceStore.containsId(cardImageId)) {
if (cardImageId.equals("card.image.1")) {
remoteResourceStore.addResource(cardImages[0]);
} else if (cardImageId.equals("card.image.2")) {
remoteResourceStore.addResource(cardImages[1]);
} else if (cardImageId.equals("card.image.3")) {
remoteResourceStore.addResource(cardImages[2]);
} else if (cardImageId.equals("card.image.4")) {
remoteResourceStore.addResource(cardImages[3]);
} else if (cardImageId.equals("card.image.5")) {
remoteResourceStore.addResource(cardImages[4]);
} else if (cardImageId.equals("card.image.6")) {
remoteResourceStore.addResource(cardImages[5]);
}
}
}
}
// Read an image from res\drawable and return as a bitmap
private Bitmap getBitmap(String fileName) throws Exception {
try {
InputStream in = getAssets().open(fileName);
return BitmapFactory.decodeStream(in);
}
catch (Exception e) {
throw new Exception("An error occurred getting the bitmap: " + fileName, e);
}
}
// Create FSM cards with content as pngs of people involved.
private RemoteDeckOfCards createDeckOfCards() {
listCard = new ListCard();
// Art Goldberg card
simpleTextCard = new SimpleTextCard("Art Goldberg");
simpleTextCard.setMessageText(new String[]{"Art Goldberg", "Draw Text: Now"});
simpleTextCard.setCardImage(remoteResourceStore, cardImages[0]);
simpleTextCard.setReceivingEvents(true);
listCard.add(simpleTextCard);
// Jack Weinberg card
simpleTextCard = new SimpleTextCard("Jack Weinberg");
simpleTextCard.setMessageText(new String[]{"Jack Weinberg", "Draw Text: FSM"});
simpleTextCard.setCardImage(remoteResourceStore, cardImages[1]);
simpleTextCard.setReceivingEvents(true);
listCard.add(simpleTextCard);
// Jackie Goldberg card
simpleTextCard = new SimpleTextCard("Jackie Goldberg");
simpleTextCard.setMessageText(new String[]{"Jackie Goldberg", "Draw Text: SLATE"});
simpleTextCard.setCardImage(remoteResourceStore, cardImages[2]);
simpleTextCard.setReceivingEvents(true);
listCard.add(simpleTextCard);
// Joan Baez card
simpleTextCard = new SimpleTextCard(("Joan Baez"));
simpleTextCard.setMessageText(new String[]{"Joan Baez", "Draw Image of: A Megaphone"});
simpleTextCard.setCardImage(remoteResourceStore, cardImages[3]);
simpleTextCard.setReceivingEvents(true);
listCard.add(simpleTextCard);
// Mario Savio card
simpleTextCard = new SimpleTextCard("Mario Savio");
simpleTextCard.setMessageText(new String[]{"Mario Savio", "Express your own view of Free Speech in an image"});
simpleTextCard.setCardImage(remoteResourceStore, cardImages[4]);
simpleTextCard.setReceivingEvents(true);
listCard.add(simpleTextCard);
// Michael Rossman
simpleTextCard = new SimpleTextCard("Michael Rossman");
simpleTextCard.setMessageText(new String[]{"Michael Rossman", "Draw Text: Free Speech"});
simpleTextCard.setCardImage(remoteResourceStore, cardImages[5]);
simpleTextCard.setReceivingEvents(true);
listCard.add(simpleTextCard);
return new RemoteDeckOfCards(this, listCard);
}
/**
* @see android.app.Activity#onStart()
*/
protected void onStart() {
super.onStart();
// Add the listeners
deckOfCardsManager.addDeckOfCardsEventListener(deckOfCardsEventListener);
// If not connected, try to connect
if (!deckOfCardsManager.isConnected()) {
try {
deckOfCardsManager.connect();
}
catch (RemoteDeckOfCardsException e) {
e.printStackTrace();
}
}
}
// Installs Free Speech Watch applet on Toq
public void install(View view) {
try {
deckOfCardsManager.installDeckOfCards(remoteDeckOfCards, remoteResourceStore);
}
catch (RemoteDeckOfCardsException e) {
e.printStackTrace();
try { // This is mostly for quick debugging purposes
deckOfCardsManager.uninstallDeckOfCards();
deckOfCardsManager.installDeckOfCards(remoteDeckOfCards, remoteResourceStore);
} catch (RemoteDeckOfCardsException e2) {
e2.printStackTrace();
}
}
}
// Handle card events triggered by the user interacting with a card in the installed deck of cards
private class mDeckOfCardsEventListener implements DeckOfCardsEventListener {
/**
* Removes Install button from main activity view and brings DrawingView to focus
* @see com.qualcomm.toq.smartwatch.api.v1.deckofcards.DeckOfCardsEventListener#onCardOpen(java.lang.String)
*/
public void onCardOpen(final String cardId) {
runOnUiThread(new Runnable() {
public void run() {
if (cardId.equals(notificationCardSent)) {
View v = findViewById(R.id.relative_view);
v.setVisibility(View.GONE);
v = findViewById(R.id.hide1);
v.setVisibility(View.VISIBLE);
v = findViewById(R.id.drawing);
v.setVisibility(View.VISIBLE);
v = findViewById(R.id.hide2);
v.setVisibility(View.VISIBLE);
v = findViewById(R.id.select);
v.setVisibility(View.VISIBLE);
v = findViewById(R.id.upload_button);
v.setVisibility(View.VISIBLE);
}
}
});
}
/**
* @see com.qualcomm.toq.smartwatch.api.v1.deckofcards.DeckOfCardsEventListener#onCardVisible(java.lang.String)
*/
public void onCardVisible(final String cardId) {
runOnUiThread(new Runnable() {
public void run() {
// Do nothing
}
});
}
/**
* @see com.qualcomm.toq.smartwatch.api.v1.deckofcards.DeckOfCardsEventListener#onCardInvisible(java.lang.String)
*/
public void onCardInvisible(final String cardId) {
runOnUiThread(new Runnable() {
public void run() {
// Do nothing
}
});
}
/**
* @see com.qualcomm.toq.smartwatch.api.v1.deckofcards.DeckOfCardsEventListener#onCardClosed(java.lang.String)
*/
public void onCardClosed(final String cardId) {
runOnUiThread(new Runnable() {
public void run() {
// Do nothing
}
});
}
/**
* @see com.qualcomm.toq.smartwatch.api.v1.deckofcards.DeckOfCardsEventListener#onMenuOptionSelected(java.lang.String, java.lang.String)
*/
public void onMenuOptionSelected(final String cardId, final String menuOption) {
runOnUiThread(new Runnable() {
public void run() {
// Do nothing
}
});
}
/**
* @see com.qualcomm.toq.smartwatch.api.v1.deckofcards.DeckOfCardsEventListener#onMenuOptionSelected(java.lang.String, java.lang.String, java.lang.String)
*/
public void onMenuOptionSelected(final String cardId, final String menuOption, final String quickReplyOption) {
runOnUiThread(new Runnable() {
public void run() {
// Do nothing
}
});
}
}
public void initLocation() {
// Acquire a reference to the system LocationManager
LocationManager locationManager = (LocationManager) this.getSystemService(Context.LOCATION_SERVICE);
// Set the destination to trigger Toq notification
destination = new Location("Destination");
destination.setLatitude(37.86965);
destination.setLongitude(-122.25914);
// Define a listener that responds to location updates
LocationListener locationListener = new LocationListener() {
@Override
public void onLocationChanged(Location location) {
// Called when a new location is found by the network location provider
float distance = location.distanceTo(destination);
if (distance <= 50.00) {
sendNotification();
}
}
@Override
public void onStatusChanged(String s, int i, Bundle bundle) {
// Do nothing
}
@Override
public void onProviderEnabled(String s) {
// Do nothing
}
@Override
public void onProviderDisabled(String s) {
// Do nothing
}
};
// Register the listener with the LocationManager to receive location updates
if (locationManager.isProviderEnabled(LocationManager.NETWORK_PROVIDER)) {
// Get update every 3 minutes
locationManager.requestLocationUpdates(LocationManager.NETWORK_PROVIDER, 180000, 0, locationListener);
}
if (locationManager.isProviderEnabled(LocationManager.GPS_PROVIDER)) {
// Get update every 3 minutes
locationManager.requestLocationUpdates(LocationManager.GPS_PROVIDER, 180000, 0, locationListener);
}
}
// Send notificationCard to prompt user to draw a random picture with DrawingView
private void sendNotification() {
String[] nameList = {"Art Goldberg", "Jack Weinberg", "Jackie Goldberg",
"Joan Baez", "Mario Savio", "Michael Rossman"};
Random random = new Random();
int randomCard = random.nextInt(nameList.length);
// Initialize string reference for the cardId sent as a notification
notificationCardSent = nameList[randomCard];
String[] messageText = {notificationCardSent};
NotificationTextCard notificationCard = new NotificationTextCard(System.currentTimeMillis(),
"Draw Request", messageText);
notificationCard.setVibeAlert(true);
RemoteToqNotification notification = new RemoteToqNotification(this, notificationCard);
try {
deckOfCardsManager.sendNotification(notification);
} catch (RemoteDeckOfCardsException e) {
Toast.makeText(this, "Error sending notification", Toast.LENGTH_SHORT).show();
}
}
// Selects a photo to add to drawing activity
public void select(View view) {
Intent intent = new Intent();
intent.setType("image/*");
intent.setAction(Intent.ACTION_GET_CONTENT);
intent.setFlags(Intent.FLAG_ACTIVITY_EXCLUDE_FROM_RECENTS);
startActivityForResult(intent, 102);
}
protected void onActivityResult(int requestCode, int resultCode, Intent data) {
super.onActivityResult(requestCode, resultCode, data);
if (requestCode == 102) {
if (resultCode == Activity.RESULT_OK) {
Uri tempFileUrl = data.getData();
String imagePath = getPath(tempFileUrl);
fileUri = new File(imagePath);
}
}
};
public String getPath(Uri uri) {
String[] projection = {MediaStore.Images.Media.DATA};
Cursor cursor = managedQuery(uri, projection, null, null, null);
int column_index = cursor.getColumnIndexOrThrow(MediaStore.Images.Media.DATA);
cursor.moveToFirst();
return cursor.getString(column_index);
}
// Upload a drawing to Flickr with tag: cs160fsm
public void pushFlickrImage(View view) {
if (fileUri == null) {
Toast.makeText(getApplicationContext(), "Please pick a photo", Toast.LENGTH_SHORT).show();
} else {
Intent intent = new Intent(getApplicationContext(),
FlickrjActivity.class);
intent.putExtra("flickImagePath", fileUri.getAbsolutePath());
getFlickrImage();
startActivity(intent);
}
}
// Gets an image from Flickr to be added to the current remoteDeckOfCards
private void getFlickrImage() {
Thread thread = new Thread() {
@Override
public void run() {
try {
String svr = "www.flickr.com";
REST rest = new REST();
rest.setHost(svr);
// Initialize Flickr object with key and REST
Flickr flickr = new Flickr(FlickrHelper.API_KEY, rest);
// Initialize SearchParameter object.
// This object stores the search keyword
SearchParameters searchParameters = new SearchParameters();
searchParameters.setSort(SearchParameters.INTERESTINGNESS_DESC);
// Create String[] for Flickr keyword tag
String[] tags = new String[]{"cs160fsm"};
searchParameters.setTags(tags);
// Initialize PhotoInterface object.
PhotosInterface photosInterface = flickr.getPhotosInterface();
// Execute search with specified tags
PhotoList photoList = photosInterface.search(searchParameters, 20, 1);
// Get search result and fetch the photo obj and get small square image's url
if (photoList != null) {
// Get search result and check the size of photo result
Random rand = new Random();
int seed = rand.nextInt(photoList.size());
// Get photo object
Photo photo = photoList.get(seed);
// Get small square url photo
InputStream inputStream = photo.getMediumAsStream();
Bitmap bitmap = BitmapFactory.decodeStream(inputStream);
// Initialize Card object to be added to Toq with the correct image dimensions
final CardImage cardImage = new CardImage("new card", Bitmap.createScaledBitmap(bitmap, WIDTH, HEIGHT, false));
runOnUiThread(new Runnable() {
@Override
public void run() {
// Add a new card we downloaded from flickr to our remoteDeckOfCards
simpleTextCard = new SimpleTextCard("flickr.card");
simpleTextCard.setHeaderText("Flickr Card");
simpleTextCard.setCardImage(remoteResourceStore, cardImage);
listCard.add(simpleTextCard);
updateDeckOfCards();
}
});
}
} catch (ParserConfigurationException e) {
e.printStackTrace();
} catch (FlickrException e) {
e.printStackTrace();
} catch (IOException e) {
e.printStackTrace();
} catch (JSONException e) {
e.printStackTrace();
}
}
};
thread.start();
}
// Update the deck of cards
private void updateDeckOfCards() {
try {
deckOfCardsManager.updateDeckOfCards(remoteDeckOfCards, remoteResourceStore);
}
catch (RemoteDeckOfCardsException e) {
Toast.makeText(this, "Error updating deck of cards", Toast.LENGTH_SHORT).show();
}
}
public void initDrawing() {
drawView = (DrawingView)findViewById(R.id.drawing);
LinearLayout paintLayout = (LinearLayout) findViewById(R.id.paint_colors);
currPaint = (ImageButton)paintLayout.getChildAt(0);
currPaint.setImageDrawable(getResources().getDrawable(R.drawable.paint_pressed));
smallBrush = getResources().getInteger(R.integer.small_size);
mediumBrush = getResources().getInteger(R.integer.medium_size);
largeBrush = getResources().getInteger(R.integer.large_size);
drawBtn = (ImageButton)findViewById(R.id.draw_btn);
eraseBtn = (ImageButton)findViewById(R.id.erase_btn);
newBtn = (ImageButton)findViewById(R.id.new_btn);
saveBtn = (ImageButton)findViewById(R.id.save_btn);
}
// Choose brush size
public void onDraw(View view) {
final Dialog brushDialog = new Dialog(this);
brushDialog.setTitle("Brush size:");
brushDialog.setContentView(R.layout.brush_chooser);
ImageButton smallBtn = (ImageButton)brushDialog.findViewById(R.id.small_brush);
smallBtn.setOnClickListener(new View.OnClickListener(){
@Override
public void onClick(View v) {
drawView.setBrushSize(smallBrush);
drawView.setLastBrushSize(smallBrush);
drawView.setErase(false);
brushDialog.dismiss();
}
});
ImageButton mediumBtn = (ImageButton)brushDialog.findViewById(R.id.medium_brush);
mediumBtn.setOnClickListener(new View.OnClickListener(){
@Override
public void onClick(View v) {
drawView.setBrushSize(mediumBrush);
drawView.setLastBrushSize(mediumBrush);
drawView.setErase(false);
brushDialog.dismiss();
}
});
ImageButton largeBtn = (ImageButton)brushDialog.findViewById(R.id.large_brush);
largeBtn.setOnClickListener(new View.OnClickListener(){
@Override
public void onClick(View v) {
drawView.setBrushSize(largeBrush);
drawView.setLastBrushSize(largeBrush);
drawView.setErase(false);
brushDialog.dismiss();
}
});
brushDialog.show();
}
public void onErase(View view) {
final Dialog brushDialog = new Dialog(this);
brushDialog.setTitle("Eraser size:");
brushDialog.setContentView(R.layout.brush_chooser);
ImageButton smallBtn = (ImageButton)brushDialog.findViewById(R.id.small_brush);
smallBtn.setOnClickListener(new View.OnClickListener(){
@Override
public void onClick(View v) {
drawView.setErase(true);
drawView.setBrushSize(smallBrush);
brushDialog.dismiss();
}
});
ImageButton mediumBtn = (ImageButton)brushDialog.findViewById(R.id.medium_brush);
mediumBtn.setOnClickListener(new View.OnClickListener(){
@Override
public void onClick(View v) {
drawView.setErase(true);
drawView.setBrushSize(mediumBrush);
brushDialog.dismiss();
}
});
ImageButton largeBtn = (ImageButton)brushDialog.findViewById(R.id.large_brush);
largeBtn.setOnClickListener(new View.OnClickListener(){
@Override
public void onClick(View v) {
drawView.setErase(true);
drawView.setBrushSize(largeBrush);
brushDialog.dismiss();
}
});
brushDialog.show();
}
// Prompt user to start a new drawing before calling invalidate in DrawingView
public void startNew(View view) {
AlertDialog.Builder newDialog = new AlertDialog.Builder(this);
newDialog.setTitle("New drawing");
newDialog.setMessage("Start new drawing (you will lose the current drawing)?");
newDialog.setPositiveButton("Yes", new DialogInterface.OnClickListener(){
public void onClick(DialogInterface dialog, int which){
drawView.startNew();
dialog.dismiss();
}
});
newDialog.setNegativeButton("Cancel", new DialogInterface.OnClickListener(){
public void onClick(DialogInterface dialog, int which){
dialog.cancel();
}
});
newDialog.show();
}
// Alert user if they want to save an image to the gallery then save and destroy it
public void onSave(View view) {
AlertDialog.Builder saveDialog = new AlertDialog.Builder(this);
saveDialog.setTitle("Save drawing");
saveDialog.setMessage("Save drawing to device Gallery?");
saveDialog.setPositiveButton("Yes", new DialogInterface.OnClickListener(){
public void onClick(DialogInterface dialog, int which){
//save drawing
drawView.setDrawingCacheEnabled(true);
// Write image to file
String imgSaved = MediaStore.Images.Media.insertImage(
getContentResolver(), drawView.getDrawingCache(),
UUID.randomUUID().toString()+".png", "drawing");
if(imgSaved!=null){
Toast savedToast = Toast.makeText(getApplicationContext(),
"Drawing saved to Gallery!", Toast.LENGTH_SHORT);
savedToast.show();
}
else{
Toast unsavedToast = Toast.makeText(getApplicationContext(),
"Oops! Image could not be saved.", Toast.LENGTH_SHORT);
unsavedToast.show();
}
drawView.destroyDrawingCache();
}
});
saveDialog.setNegativeButton("Cancel", new DialogInterface.OnClickListener(){
public void onClick(DialogInterface dialog, int which){
dialog.cancel();
}
});
saveDialog.show();
}
// Use chosen color
public void paintClicked(View view) {
drawView.setErase(false);
if (view != currPaint) {
// update color
ImageButton imgView = (ImageButton) view;
String color = view.getTag().toString();
drawView.setColor(color);
drawView.setBrushSize(drawView.getLastBrushSize());
imgView.setImageDrawable(getResources().getDrawable(R.drawable.paint_pressed));
currPaint.setImageDrawable(getResources().getDrawable(R.drawable.paint));
currPaint=(ImageButton)view;
}
}
@Override
public boolean onCreateOptionsMenu(Menu menu) {
// Inflate the menu; this adds items to the action bar if it is present.
getMenuInflater().inflate(R.menu.main, menu);
return true;
}
@Override
public boolean onOptionsItemSelected(MenuItem item) {
// Handle action bar item clicks here. The action bar will
// automatically handle clicks on the Home/Up button, so long
// as you specify a parent activity in AndroidManifest.xml.
int id = item.getItemId();
if (id == R.id.action_settings) {
return true;
}
return super.onOptionsItemSelected(item);
}
}
package com.example.cshort.drawingapplication;
import android.content.Context;
import android.graphics.Bitmap;
import android.graphics.Canvas;
import android.graphics.Color;
import android.graphics.Path;
import android.graphics.Paint;
import android.graphics.PorterDuff;
import android.graphics.PorterDuffXfermode;
import android.util.AttributeSet;
import android.util.TypedValue;
import android.view.MotionEvent;
import android.view.View;
/**
* Created by Short on 10/8/2014.
* Reference to code at http://creative-punch.net/2014/03/make-basic-single-touch-drawing-app-android/
* and http://code.tutsplus.com/tutorials/android-sdk-create-a-drawing-app-touch-interaction--mobile-19202
*/
public class DrawingView extends View {
//drawing path
private Path drawPath;
//drawing and canvas paint
private Paint drawPaint, canvasPaint;
//initial color
private int paintColor = 0xFF660000;
//canvas
private Canvas drawCanvas;
//canvas bitmap
private Bitmap canvasBitmap;
private float brushSize, lastBrushSize;
private boolean erase = false;
// Constructor
public DrawingView(Context context, AttributeSet attrs) {
super(context, attrs);
init();
}
// Get the drawing canvas and view setup
private void init() {
brushSize = getResources().getInteger(R.integer.medium_size);
lastBrushSize = brushSize;
drawPath = new Path();
drawPaint = new Paint();
drawPaint.setColor(paintColor);
drawPaint.setAntiAlias(true);
drawPaint.setStrokeWidth(20);
drawPaint.setStyle(Paint.Style.STROKE);
drawPaint.setStrokeJoin(Paint.Join.ROUND);
drawPaint.setStrokeCap(Paint.Cap.ROUND);
canvasPaint = new Paint(Paint.DITHER_FLAG);
}
@Override
protected void onSizeChanged(int w, int h, int oldw, int oldh) {
super.onSizeChanged(w, h, oldw, oldh);
canvasBitmap = Bitmap.createBitmap(w, h, Bitmap.Config.ARGB_8888);
drawCanvas = new Canvas(canvasBitmap);
}
@Override
public void onDraw(Canvas canvas) {
canvas.drawBitmap(canvasBitmap, 0, 0, canvasPaint);
canvas.drawPath(drawPath, drawPaint);
}
// Set erase true or false
public void setErase(boolean isErase) {
erase=isErase;
if(erase) drawPaint.setXfermode(new PorterDuffXfermode(PorterDuff.Mode.CLEAR));
else drawPaint.setXfermode(null);
}
// Start new drawing
public void startNew(){
drawCanvas.drawColor(0, PorterDuff.Mode.CLEAR);
invalidate();
}
@Override
public boolean onTouchEvent(MotionEvent event) {
float CoordX = event.getX();
float CoordY = event.getY();
// expects an ACTION_DOWN or ACTION_MOVE MotionEvent
switch (event.getAction()) {
case MotionEvent.ACTION_DOWN: // a pressed gesture has began
drawPath.moveTo(CoordX, CoordY); // sets starting point of path
break;
// change during a gesture that has the most recent point
case MotionEvent.ACTION_MOVE:
drawPath.lineTo(CoordX, CoordY); // connects the points for path
break;
case MotionEvent.ACTION_UP:
drawCanvas.drawPath(drawPath, drawPaint);
drawPath.reset();
break;
default: // no event detected
return false;
}
// Makes our view repaint and call onDraw()
invalidate();
return true;
}
// Set color
public void setColor(String newColor){
invalidate();
paintColor = Color.parseColor(newColor);
drawPaint.setColor(paintColor);
}
// update brush size
public void setBrushSize(float newSize){
float pixelAmount = TypedValue.applyDimension(TypedValue.COMPLEX_UNIT_DIP,
newSize, getResources().getDisplayMetrics());
brushSize=pixelAmount;
drawPaint.setStrokeWidth(brushSize);
}
public void setLastBrushSize(float lastSize){
lastBrushSize=lastSize;
}
public float getLastBrushSize(){
return lastBrushSize;
}
}
Comments
